Miele MOPSTAR 60 - Page 10

PWM 506/508 en-GB
 = standard,  = optional, + = only on request, - not available
10 11 276 310/11
Technical data
PWM 506 DV
PWM 508 DV
PWM 506 DP
PWM 508 DP
Standard voltage (B only)
2N AC 230 V
2N AC 230 V
2N AC 230 V
2N AC 230 V
Frequency
Hz
50
50
50
50
Total rated load
kW
4.8
4.8
4.8
4.8
Fuse rating (B trip rating according to EN 60898)
A
2 x 16
2 x 16
2 x 16
2 x 16
Supply lead min. cross-section
mm²
4 x 2.5
4 x 2.5
4 x 2.5
4 x 2.5
Supply lead without plug




Length of supply lead
mm
2000
2000
2000
2000
Alternative voltage (convertible)
3 AC 230 V
3 AC 230 V
3 AC 230 V
3 AC 230 V
Total rated load
kW
4.8
4.8
4.8
4.8
Fuse rating (B trip rating according to EN 60898)
A
3 x 20
3 x 20
3 x 20
3 x 20
Supply lead min. cross-section
mm²
4 x 2.5
4 x 2.5
4 x 2.5
4 x 2.5
Alternative voltage (convertible)
1N AC 230 V
1N AC 230 V
1N AC 230 V
1N AC 230 V
Total rated load
kW
2.5
2.5
2.5
2.5
Fuse rating (B trip rating according to EN 60898)
A
1 x 16
1 x 16
1 x 16
1 x 16
Supply lead min. cross-section
mm²
3 x 1.5
3 x 1.5
3 x 1.5
3 x 1.5
Standard voltage (AUS only)
1N AC 230 V
Frequency
Hz
50
Total rated load
kW
4.8
Fuse rating
A
1 x 25
Supply lead min. cross-section
mm²
3 x 2.5
Supply lead without plug

Length of supply lead
mm
2000
Cold water (KW)
Permissible water flow pressure
kPa
100–1000
100–1000
100–1000
100–1000
Required flow rate (cold water connection only)
l/min
11
11
11
11
Required flow rate (with additional hot water connection)
l/min
10
10
10
10
Average water consumption (60 °C standard programme)
l/h
36
36
36
36
Connection to be provided on site, external thread according to DIN 44991 (flat seal)
Inch
¾"
¾"
¾"
¾"
Connection hose ½" with ¾" threaded union




Connection hose length
mm
1550
1550
1550
1550
Hot water (WW)
Max. water intake temperature
°C
60
60
60
60
Permissible water flow pressure
kPa
100–1000
100–1000
100–1000
100–1000
Required flow rate
l/min
11
11
11
11
Average water consumption (60 °C standard programme)
l/h
13
13
13
13
Connection to be provided on site, external thread according to DIN 44991 (flat seal)
Inch
¾"
¾"
¾"
¾"
Connection hose ½" with ¾" threaded union




Connection hose length
mm
1550
1550
1550
1550
Drain valve (DV)
Connection (ext. diameter)
mm
75 (DN 70)
75 (DN 70)
75 (DN 70)
75 (DN 70)
Max. drainage temperature
°C
90
90
90
90
Max. transient flow rate
l/min
62
62
62
62
Drain pump (DP)
Hose connection (external diameter)
mm
-
-
22 (DN 22)
22 (DN 22)
Max. drainage temperature
°C
-
-
90
90
On-site hose sleeve (int. diameter x length)
mm
-
-
22 x 30
22 x 30
Max. transient flow rate
l/min
-
-
26
26
Max. delivery head (from lower edge of machine)
mm
-
-
1000
1000
Drain hose DN 22 with connector (supplied as standard)
-
-


Connection hose length
mm
-
-
1500
1500
