Miele PDR 514 - Page 41

Installation
41
PDR514/518/522/914/918/922 PDR528/544/928/944
x 1400mm 1640mm
y 906mm 1206mm
z PDR514/914: 852mm
PDR518/918: 1035mm
PDR522/922: 1164mm
PDR528/928: 1018mm
PDR544/944: 1384mm
 To facilitate any future maintenance work, a maintenance corridor with a width of at least
500mm must be set up behind the machine and must be accessible at all times. The dis-
tance between the machine and any walls must not fall below the specified minimum val-
ues.
 Adjust the tumble dryer adjustable feet until the machine is level. Use a spirit level to en-
sure correct alignment.
