Miele PFD 102 i User Manual

en - Technical details
11
Electrical connection
Standard electrical connection
Voltage AC120V
Frequency 60Hz
Fuse rating 15A
Plug 5–15P NEMA
Power cord length 5.6ft/1.7m
Power cord cross-section 3xAWG14
Heat output 1.3kW
Total rated load 1.4kW
Possible voltage variant
PFD102i and PFD104SCVi only
Voltage 2NAC208–240V
Frequency 60Hz
Fuse rating 2x30A
Plug 14–30PNEMA
Power cord length 5.6ft/1.7m
Power cord cross-section 4xAWG10
Heat output 3.5–3.8kW
Total rated load 3.7–4kW
Water intake
Max. water temperature 140°F 60°C
Max. water hardness 66.5mmol/l
Max. water hardness 36°dH
Water connection pressure 5–1000kPa
On-site threaded connection (flat seal) 3/4" Hose thread
Connection hose length 4.9ft 1.5m
Connection hose extension * 4.9ft 1.5m
* Optional accessory

Miele PFD 102 i Specifications

General

Brand	Miele
Model	PFD 102 i
Category	Dishwasher
Language	English
