Miele PFD 102 i User Manual

en - Technical details
12
Drainage
Max. water temperature 180°F 82°C
Drain hose length 4.9ft 1.5m
Max. drain hose length 13ft 4m
Max. drain height 3.3ft 1m
Max. transient flow rate 10l/min
Hose inner diameter 0.87" 22mm
On-site hose sleeve (xlength) 0.87"x1.18" 22x30mm
Operating conditions
Ambient temperature +41–+104°F +5–+40°C
Relative humidity:
Up to 88°F (31°C), maximum
Linear decreasing to 104°F (40°C)
80%
50%
Max. altitude above sea level up to 13,123ft 4,000m
Storage and transportation conditions
Ambient temperature -4–+140°F -20–+60°C
Relative humidity 10–85%
Air pressure 500–1060 hPa
Min. site access dimensions including transport pallet
Height 38.2" 970mm
Width 26.4" 670mm
Depth 26.4" 670mm

Miele PFD 102 i Specifications

General

Brand	Miele
Model	PFD 102 i
Category	Dishwasher
Language	English
