Installation plan PG 8535
Version: 01.10.2010
Page 2
Technical datasheet
Washer PG 8535
Legend:
Abbreviations in bold type:
Connection required
USA
Abbreviations in circle with dashes:
Connection optional or required depending on model version
Electrical
connection
1. Voltage V/Hz 3N AC 400/50
Rated load kW 9.7
Fuse rating A 3 x 16
Min. supply lead cross-section mm² 5 x 2.5
Length of supply lead (H05(07)RN-F) with plug m 1.7
Country variations:
2. Voltage (as supplied) V/Hz 3N AC 400/50
Rated load kW 7.3
Fuse rating A 3 x 16
Min. supply lead cross-section mm² 5 x 2.5
Length of supply lead (H05(07)RN-F) without plug
m 1.7
Voltage
Convertible
V/Hz 3 AC 230/50
Rated load kW 7.3
Fuse rating A 3 x 20
Min. supply lead cross-section mm² 5 x 2.5
Length of supply lead (H05(07)RN-F) without plug
m 1.7
3. Voltage (as supplied) V/Hz 3 AC 230/50
Rated load kW 7.3
Fuse rating A 3 x 20
Min. supply lead cross-section mm² 5 x 2.5
Length of supply lead (H05(07)RN-F) without plug
m 1.7
Voltage
Convertible
V/Hz 3N AC 400/50
Rated load kW 7.3
Fuse rating A 3 x 16
Min. supply lead cross-section mm² 5 x 2.5
Length of supply lead (H05(07)RN-F) without plug
m 1.7
4. Voltage (as supplied) V/Hz 3N AC 400/50
Rated load kW 9.2
Fuse (integrated into plug) A 3 x 15/16
Min. supply lead cross-section mm² 5 x 2.5
Length of supply lead without plug m 1.7
Voltage
convertible
V/Hz AC 230/50
Rated load kW 6.7
Fuse rating A 1 x 30
Min. supply lead cross-section mm² 3 x 4.0
Length of supply lead (H05(07)RN-F) without plug
m 2.1
