Installation plan PG 8535
Version: 01.10.2010
Page 3
5. Voltage (as supplied) V/Hz AC 230/50
Rated load kW 6.7
Fuse (integrated into plug) A 1 x 30
Min. supply lead cross-section mm² 3 x 4.0
Length of supply lead without plug m 2.1
Voltage
convertible
V/Hz 3N AC 400/50
Rated load kW 9.2
Fuse rating A 3 x 15/16
Min. supply lead cross-section mm² 5 x 2.5
Length of supply lead (H05(07)RN-F) without plug
m 1.7
6. Voltage (as supplied) V/Hz 3 AC 208/60
Rated load kW 6.0
Fuse rating A 3 x 20
Min. supply lead cross-section AWG 4 x 12
Length of supply lead without plug m 1.9
Voltage
convertible
V/Hz AC 208/60
Rated load kW 6.0
Fuse rating A 2 x 30
Min. supply lead cross-section AWG 3 x 10
Length of supply lead without plug m 1.9
7. Voltage (as supplied) V/Hz AC 208/60
Rated load kW 6.0
Fuse rating A 2 x 30
Min. supply lead cross-section AWG 3 x 10
Length of supply lead without plug m 1.9
Voltage
convertible
V/Hz 3 AC 208/60
Rated load kW 6.0
Fuse rating A 3 x 20
Min. supply lead cross-section AWG 4 x 12
Length of supply lead without plug m 1.9
8. Voltage (as supplied) V/Hz 3 AC 200/50
Rated load kW 5.7
Fuse rating A 3 x 20
Min. supply lead cross-section mm² 5 x 2.5
Length of supply lead (H05(07)RN-F) without plug
m 2.3
Voltage
convertible
V/Hz AC 200/50
Rated load kW 5.7
Fuse rating A 2 x 30
Min. supply lead cross-section mm² 3 x 4
Length of supply lead (H05(07)RN-F) without plug
m 2.1
9. Voltage (as supplied) V/Hz 3 AC 200/60
Rated load kW 5.7
Fuse rating A 3 x 20
Min. supply lead cross-section mm² 5 x 2.5
Length of supply lead (H05(07)RN-F) without plug
m 2.3
Voltage
convertible
V/Hz AC 200/60
Rated load kW 5.7
Fuse rating A 2 x 30
Min. supply lead cross-section mm² 3 x 4.0
Length of supply lead (H05(07)RN-F) without plug
m 2.1
