Installation plan PG 8535
Version: 01.10.2010
Page 5
(Optional)
Connection
module
Output signals
Potential-free contacts (NO contacts)
A maximum of 9 contacts are available, Possible
assignment:
Contact load
Max.:
TA OPERATION Contact closed during drying block V/A/Hz 200-240/1/50-60
PRG RUNNING Contact closed during washing, drying and cool-down V/A/Hz 200-240/1/50-60
OPERATION Contact closed while machine is running V/A/Hz 200-240/1/50-60
FAULT Contact closed when fault occurs V/A/Hz 200-240/1/50-60
PRG END Contact closed between end of programme and door opening V/A/Hz 200-240/1/50-60
PAUSE w.
WASH
Contact closed during 'Pause with wash action' stage V/A/Hz 200-240/1/50-60
DRAINAG Contact closed during drainage V/A/Hz 200-240/1/50-60
User-defined Contact activated during drainage if plug ST 6.1 to ST 6.5 is
programmed in 'External contact - Drainage' block.
V/A/Hz 200-240/1/50-60
COLD Contact closed during cold water intake V/A/Hz 200-240/1/50-60
HOT Contact closed during hot water intake V/A/Hz 200-240/1/50-60
AD Contact closed during de-mineralised water intake V/A/Hz 200-240/1/50-60
Cold delayed Output according to parameters V/A/Hz 200-240/1/50-60
Hot delayed Delay switch-off valve: V/A/Hz 200-240/1/50-60
De-min. delayed a. Delayed (start of water intake) V/A/Hz 200-240/1/50-60
b. Brought forwards (end of water intake) V/A/Hz 200-240/1/50-60
DOS1-
EXTERNAL
Control signal for external dispenser pump 1 V/A/Hz 200-240/1/50-60
DOS2-
EXTERNAL
Control signal for external dispenser pump 2 V/A/Hz 200-240/1/50-60
DOS3-EXT Control signal for external dispenser pump 3 V/A/Hz 200-240/1/50-60
DOS4-EXT Control signal for external dispenser pump 4 V/A/Hz 200-240/1/50-60
DOS5-EXT Control signal for external dispenser pump 5 V/A/Hz 200-240/1/50-60
DOS6-EXT Control signal for external dispenser pump 6 V/A/Hz 200-240/1/50-60
DOS7-EXT Control signal for external dispenser pump 7 V/A/Hz 200-240/1/50-60
DOS8-EXT Control signal for external dispenser pump 8 V/A/Hz 200-240/1/50-60
DOS9-EXT Control signal for external dispenser pump 9 V/A/Hz 200-240/1/50-60
Information DOS
1
Contact activated when appropriate pump is activated during
the programme
V/A/Hz 200-240/1/50-60
Information DOS
2
Contact activated when appropriate pump is activated during
the programme
V/A/Hz 200-240/1/50-60
Information DOS
3
Contact activated when appropriate pump is activated during
the programme
V/A/Hz 200-240/1/50-60
Information DOS
4
Contact activated when appropriate pump is activated during
the programme
V/A/Hz 200-240/1/50-60
Information DOS
5
Contact activated when appropriate pump is activated during
the programme
V/A/Hz 200-240/1/50-60
Connection
module
Input signals
Control voltage
SLA HZG Peak-load negotiation - Heating V/Hz 200-240/50-60
DOS-EXT Fill level of external dispenser canister V/Hz 200-240/50-60
MEDIUM Medium dispensing active, signal for flow and volume control V/Hz 200-240/50-60
EXT TEXT External text V/Hz 200-240/50-60
Cold water Second cold water inlet hose.
can be connected using Y-piece supplied.
Max. temperature °C 20
Max. water hardness °dH 60
Min. flow pressure kPa 250
Max. pressure kPa 1000
Throughput l/min 8
Connection thread (on site) Inch
¾ external
(USA: 11.5 NH)
Length of connection hose (supplied) mm 1500
Length of steam condenser connection hose (supplied) mm 1500
DVGW certification. Direct connection without fuse box
permissible.
