Installation plan PG 8535
Version: 01.10.2010
Page 6
Hot water Max. temperature °C 70
Max. water hardness °dH 60
Min. flow pressure kPa 250
Max. pressure kPa 1000
Throughput l/min 8
Connection thread (on site) Inch ¾ external
(USA: 11.5 NH)
Length of connection hose (supplied) mm 1500
DVGW certification.
Direct connection without fuse box permissible.
De-min. water Standard version:
Min. flow pressure kPa 250
Min. flow pressure with extended fill time kPa 100
Max. pressure kPa 1000
Throughput l/min 8
Length of connection hose (supplied) mm 1500
Connection thread (on site) Inch ¾ external
(USA: 11.5 NH)
Version with demineralised water feed pump (ADP):
Min. flow pressure kPa 5
Max. pressure kPa 30
Connection nipple (ext. dia. × length) mm 6 x 30
Hose from container to machine to be provided on site
Effluent Two drain hoses provided.
Drain hose (Int. dia. × wall thickness × l)
Drain pump (supplied) mm 22 x 6 x 1500
Steam condenser (supplied as standard) mm 22 x 6 x 1500
Drain pump head height from floor level, max. m 1.0
Max. transient throughput – Drain hose l/min 50
On-site hose connector (Ext. dia. × l)
Drain pump mm 22 x 30
Steam condenser mm 22 x 30
External
dispenser
(optional)
Connection for dispenser for chem. disinfection (DOS G 60)
and dispenser for surfactant (DOS G 10) on rear
Machine data Building-under height mm 820
Height incl. lid mm 850
Width mm 900
Depth mm 600
Depth with side panels removed (ex works) mm 700
Net weight kg 180
Dynamic floor load N 2000
Min. transport width incl. pallet mm 800
Min. transport height incl. pallet mm 1100
Good floor contact required with plinths (UC 30-90/60-78, UC 30-90/70-78). Machine anchors required.
Observe installation instructions when installing machine! Only commercial-grade cabinets should be used in the vicinity of a
washer-disinfector to avoid any damage caused by condensate.
Installation should only be carried out by authorised fitters in accordance with valid regulations!
Observe installation instructions when installing machine! All rights reserved! Measurements in mm
Änderungsnr. Datum Bezeichnung:
A13444
