page5/14 InstallationplanPG8582CD/PG8583CD
Demineralised water (VE)
Max. temperature 150 °F 65 °C
Max. water hardness 29 psi 200 kPa
Recommended flow pressure 4.4 psi 30 kPa
Min. flow pressure 145 psi 1,000 kPa
Max. pressure 2 gal/min 7.5 l/min
Connection thread - on site (flat sealing) 11.5 NH
3/4“ Male Garden
Hose Thread
Length of connection hose (supplied) approx. 5‘ 7“ approx. 1.7 m
Machines with a booster pump for demineralised water (ADP) are only suitable for connection/use with a
non-pressurised system.
Minimum flow pressure (AD unpressurised) 1,3 psi 8.5 kPa
Maximum pressure (AD unpressurised) 8.7 psi 60 kPa
Machine connection nipple (outer dia. x l) 1/4“ x 3/16“ 6 x 30 mm
Drain water (AW)
Drainage temperature 200 °F 93 °C
Length of Commercial Dishwasher drain hose approx. 4’ 11” approx. 1.5 m
Drain hose, max. drainage length approx. 13’ 1” approx. 4.0 m
Drain pump head height from floor level, max. approx. 3’ 3” approx. 1 m
Drain hose delivery, max. 4.2 gal/min 16 l/min
On-site hose connector (external diameter x length) 7/8” × 1 3/16” 22 × 30 mm
Machine feet
Height adjustable 0 - 5/16“ 0-8 mm
Foot diameter 1 3/8“ 35 mm
Entry point into housing 8 M 8 M
Machine data
Unit height 32 1/4“ 820 mm
Height including cover 32 7/8“ 835 mm
Width 23 9/16“ 598 mm
Depth 27 1/2“ 698 mm
Door height 24 1/2“ 622 mm
Net weight 216 lbs 98 kg
Dynamic floor load 2.000 N 2.000 N
Width including transport pallet 46 1/16“ 1.170 mm
Depth including transport pallet 29 1/8“ 740 mm
Height including transport pallet 39 3/8“ 1.000 mm
Sound emissions in dB (A),
Sound pressure LpA, washing and drying
< 70 dB < 70 dB
