Installation and planning notes
PW 811 / PW 814 / PW 818 15
Dispenser pump connections
Up to 12dispenser pumps can be connected to the washing
machine.
It is particularly important to observe manufacturer's instructions
when using a combination of cleaning agents and special
application products.
Dispenser pump connections on the back of the machine
Connections 1 and 2 are provided for viscous agents. These
connections are sealed and need to be drilled open using an 8mm
drill bit before connecting.
Make sure that you only drill through the first panel(I) as there is a
deflecting panel(II) 10mm behind it.
Connections 3 to 12 are provided for liquid detergent. These
connections are sealed and must be cut to the diameter of the hose
with a small saw.
If opened connections are no longer required, they must be resealed
using a suitable sealant (e.g. silicone).
