Technical data
30 PW 811 / PW 814 / PW 818
Water connection
Models with detergent dispenser drawer (WEK)
Permitted flow pressure 1-10 bar
Maximum intake rate 79.5 l/min
Cold water connection
(on-site external thread according to AS3688, flat seal)
2 x ¾" or 1 x 1"
Optional cold water connection for liquid dispensing
(on site external thread according to AS3688, flat seal)
1 x ¾"
Optional cold-hard water connection
(on site external thread according to AS3688, flat seal)
2 x ¾" or 1 x 1"
Hot water connection≤70°C
(on site external thread according to AS3688, flat seal)
1 x ¾"
Inlet hose length 1500 mm
Y-piece connector for cold water (if multiple ¾" cold connections are not available) 2x¾" to 1x1"
Models without detergent dispenser drawer (WEK)
Permitted flow pressure 1-10 bar
Maximum intake rate 69.5 l/min
Cold water connection
(on-site external thread according to AS3688, flat seal)
1 x ¾"
Cold water connection for liquid dispensing
(on site external thread according to AS3688, flat seal)
1 x ¾"
Optional cold-hard water connection
(on site external thread according to AS3688, flat seal)
2 x ¾" or 1 x 1"
Hot water connection≤70°C
(on-site external thread according to AS3688, flat seal)
1 x ¾"
Inlet hose length 1500 mm
Y-piece connector for cold water (if multiple ¾" cold connections are not available) 2x¾" to 1x1"
Drain valve
Maximum drain water temperature 95 °C
Waste water connection (on machine) Plastic pipe HTDN70
Drain (on-site) DN70 connection
Maximum drainage rate 200 l/min
Connection for equipotential bonding
Connection with male thread (machine) 10 mm x 35 mm
Washers and nuts M10
