The dryer is fitted with a non-return val-
ve as standard to prevent water from
flowing back into the machine.
Close the water inlet port to the con-
densed water container with the bot-
tom part of the rubber plug.
The plug must face towards the inte-
rior of the machine so that the con-
densed water container can be pus-
hed in easily.
Connection to wash basin drain out-
let (where appropriate)
Push the hose clip (1) and the knur-
led nut connector from the sink drain
outlet (2) over the drain hose.
Push the adapter sleeve (3) into the
hose.
Screw the drain hose to the drain out-
let with the knurled nut connector.
Tighten the hose clip up close to the
nut.
Installation
35
