3. Cleaning the fine filter in front of
the heat exchanger unit
Removing
^ Use the yellow opener to open the
service panel at the bottom left of the
front of the tumble dryer.
^ Now remove the panel by pulling it
diagonally upwards.
^ Then place it to one side.
^
Turn the lever on the inner cover
downwards to the vertical position.
^
Pull the cover forwards.
^
Remove it by pulling it diagonally
upwards.
^
Pull the fine filter out by the handle.
^
Press the stoppers gently together
and then pull them out of the handle.
^
Pull the handle out of the fine filter.
Cleaning
^
Clean the fine filter thoroughly under
running water.
^
Then squeeze the fine filter
thoroughly.
Cleaning and care
33
