Cleaning and care
29
Replacing the condenser unit
P
ush the condenser unit back into
the housing as far as it will go.
T
urn the lever down to the horizontal
position, making sure that the hook
on the lever clicks
into the groove at
the bottom.
When replacing the inner cover after
cle
aning, ensure that the rubber seal
fits correctly into the groove.
Otherwise water may leak from the
syst
em.
Replace
the inner cover making sure
the hooks are at the bottom. Hold it
at an angle and push down gently.
P
ress against the cover and lock it
with the lever.
The lever will be in the horizontal
position
when locked.
Replace
the service panel and press
the upper edge until it clicks into
position.
I
t is important to ensure that
both the condenser unit and the
cover are correctly positioned and
locked, otherwise water may leak
from the system.
