Miele WCG660 WCS User Manual

Technical data
88
Height 850mm
Width 596mm
Depth 636mm
Depth with door open 1054mm
Height for building under 820 (+8/-2)mm
Width for building under 600mm
Depth for building under 600mm
Weight Approx. 90kg
Capacity 9.0kg dry laundry
Supply voltage See data plate
Rated load See data plate
Fuse rating See data plate
Consumption data See “Consumption data”
Minimum water flow pressure 100kPa (1bar)
Maximum water flow pressure 1000kPa (10bar)
Water inlet hose length 1.60m
Drain hose length 1.50m
Connection cable length 2.00m
Maximum delivery head 1.00m
Maximum drainage length 5.00m
LEDs Class1
Test certifications awarded See data plate
Power rating in off mode 0.40W
Networked standby 0.80W
Frequency range 2.4000–2.4835GHz
Maximum transmission power <100mW

Miele WCG660 WCS Specifications

General

Brand	Miele
Model	WCG660 WCS
Category	Washer
Language	English
