Mighty Mule FM231 - Installing Transmitter Batteries; Placing Receiver and Testing System; Receiver Placement; Testing the System

4 Wireless Driveway Alarm Instruction Manual • 03.04.12
Testing the System
Placing Receiver and Testing System
Receiver Placement
Installing Transmitter Batteries
• PlacetheindoorRECEIVERinaconvenientlocation.
• PlugtheACtransformerintoa110VACoutletandthe
charger cable into the receiver.
• ThepowerLEDonthefrontpanelwilllightup,andthere
willbeaconrmation“beep”tone.
• WhenacarpassestheSENSOR,asignalistransmitted
to the RECEIVER from the TRANSMITTER. After the
RECEIVER receives the signal, it will chime and the visitor
alertLEDwillturnonandremainlit.TheLEDcanbereset
by pressing the RESET button, but it is not required.
• TheLOWBATTERYLEDalertsyouwhenthetwo(2)
“AA” batteries in the outdoor TRANSMITTER need to
be replaced.
• TesttherangeandsystembyhavingsomeonedriveanautomobilepasttheSENSORtobesure
theRECEIVERisactivatedwhenthevehiclehaspassedtheSENSOR.Kitchenappliancesorother
electronics may interfere with reception. It may be necessary to adjust the position or relocate the
RECEIVER for optimum results. See Troubleshooting Section on page 6.
• MakesuretheSENSORwireispluggedintotheTRANSMITTER.
• TemporarilyplaceTRANSMITTERonthemountingpostinground.
• WithTRANSMITTERindesiredlocationinstalltwo(2)“AA”batteries.
IMPORTANT: “AA” batteries must be installed at the site where the TRANSMITTER will be located to ensure
proper calibration of the transmitter.
Insert
“AA” Batteries
MIN MAX
SENSITIVITY
TRANSMITTER CODE
TRANSMITTING
1 2 3 4
MIN MAX
SENSITIVITY
TRANSMITTER CODE
TRANSMITTING
1 2 3 4
RESET BUTTON
LOW BATTERY LED
TRANSFORMER INPUT
VOLUME CONTROL
VISITOR LED
POWER LED
