Expansion slots and ports
Product code ATLGM&EG18-EA
CPU Dual-core 88F3720 1.2 GHz
CPU architecture ARM 64bit
Size of RAM 256 MB
RAM type DDR3L
Storage 16 MB, Flash
Number of 1G Ethernet ports 1
LTE modem R11mL-EG18-EA
TAC 86981604
LTE Category 18 (1.2Gbps Downlink, 150Mbps Uplink)
LTE bands 1 (2100MHz) / 3 (1800MHz) / 5 (850MHz) / 7 (2600MHz) / 8 (900 MHz) / 20 (800MHz) /
28 (700MHz) / 38 (2600MHz) / 40 (2300MHz) / 41 (2500MHz)
3G Category R8 (42.2Mbps Downlink, 11.2Mbps Uplink)
3G Bands 1 (2100MHz) / 3 (1800MHz) / 5 (850MHz) / 8 (900MHz)
Dimensions 315 mm diameter x 170 mm depth
Operating system RouterOS, License level 3
Operating temperature -40°C to +70°C
Reset button
The reset button has three functions:
Hold this button during boot time until the LED light starts flashing, release the button to reset
RouterOS configuration (total 5 seconds);
