Accumulator
Tank
Heater
Heater Heater Heater Heater Heater
Water
Pump
Mikuni
MX
Heater
Cold
water
feed.
Air
Separat
or
Cold water
feed
from
domestic
pump.
= 15mm
pipe
= 22mm
pipe
Hot
out
Calorifier
'A'
Heater
Heater Heater Heater Heater Heater
Water
Pump
Mikuni
MX
Heater
Header
Tank
2 - 3
Litres.
Air
Separa
tor
= 15mm
pipe
= 22mm
pipe
Hot
out
Calorifier
'A'
Plumbing Circuit Guide.
Pressurised System.
Gravity System
NOTE: 'A' is an optional gate valve for shutting off the heating circuit in the summer.
-
