Millenium MPS-750X PRO User Manual

%
&
'
(
1. Insert the connecting part (5) for the support tubes (6).
2. Place the two support tubes (6) of the tom pads in the holes of the connecting part (5).
3. Adjust the orientation of the lower memory locks (7) so the tap is pointing down.
4. Place the two tom pads in the support tubes (6) and adjust the upper memory locks (7).
Setting up the ground tom
*
)
1. Push the legs (8) of the ground tom into the connecting parts (9) on the sides.
2. Tighten the wing nuts of the fastening clamps.
Assembly
MPS-750X PRO
11
E-Drum Set

Millenium MPS-750X PRO Specifications

General

Sequencer	Yes
Type	E-Drum Set
Crash Cymbal	12" Dual-Trigger Pad
Drum Module	MPS-750
Connectivity	USB, MIDI, Aux In, Headphone Out
Additional Features	Metronome
Power Supply	AC Adapter (Included)
Tom 1	8" Single-Trigger Pad
Tom 2	8" Single-Trigger Pad
Tom 3	10" Single-Trigger Pad
