OM-279248 Page 12
SECTION 4 − SPECIFICATIONS
4-1. Serial Number And Rating Label Location
The serial number and rating information for this product is located on the back. Use rating label to determine input power requirements and/or rated
output. For future reference, write serial number in space provided on back cover of this manual.
4-2. Software Licensing Agreement
The End User License Agreement and any third-party notices and terms and conditions pertaining to third-party software can be found at
https://www
.millerwelds.com/eula
and are incorporated by reference herein.
4-3. Information About Default Weld Parameters And Settings
NOTICE − Each welding application is unique. Although certain Miller Electric products are designed to determine and default to certain typical welding
parameters and settings based upon specific and relatively limited application variables input by the end user, such default settings are for reference
purposes only; and final weld results can be affected by other variables and application-specific circumstances. The appropriateness of all parameters
and settings should be evaluated and modified by the end user as necessary based upon application-specific requirements. The end user is solely
responsible for selection and coordination of appropriate equipment, adoption or adjustment of default weld parameters and settings, and ultimate
quality and durability of all resultant welds. Miller Electric expressly disclaims any and all implied warranties including any implied warranty of fitness
for a particular purpose.
4-4. Specifications
Input Power
Welding Power
Source Type
Wire Feed Speed Range* Wire Diameter Range
Welding Circuit
Rating
Overall
Dimensions
Weight
50 VDC Deltaweld 350
Deltaweld 500
Standard:
50−780 ipm
(1.3−19.8mpm)
.023 To 5/64 in.
(0.6 To 2 mm)
Max Spool Capacity:
18 in. (457 mm)
Max Spool Weight:
60 lb (27 kg)
113 Volts DC
600 Amperes,
60% Duty
Cycle
Height:
16-1/4 in.
(413 mm)
Width:
12-3/8 in.
(314 mm)
Length:
27-7/8 in.
(708 mm)
44.8 lb
(20.3 kg)
4-5. Environmental Specifications
A. IP Rating
IP Rating
IP2X
This equipment is designed for indoor use and is not intended to be used or stored outside.
IP2X 2014−06
B. Temperature Specifications
Operating Temperature Range Storage Temperature Range
14 to 104 °F (−10 to 40°C) −4 to 131 °F (−20 to 55°C)
Temp_2016- 07
4-6. Duty Cycle
Duty Cycle is percentage of 10 min-
utes that unit can weld at rated load
without overheating.
NOTICE − Exceeding duty cycle
can damage unit and void warranty.
duty1 4/95 − SA-181560 / 263638-A
60% Duty Cycle At 600 Amperes
6 Minutes Welding 4 Minutes Resting
