Miller TM-268 - 3-4. AC Power Curve

TM-268 819 Page 6
Belt Driven Generator
3-4. AC Power Curve
209 397 / 209 398 / 265 921
The ac power curve shows the
power in amperes available from
the generator.
0
50
100
150
200
250
300
0 5 10 15 20 25 30 35 40 45 50
AC AMPERES
AC VOLTS
0
50
100
150
200
250
300
0 5 10 15 20 25 30 35 40
AC AMPERES
AC VOLTS
0
50
100
150
200
250
300
0 10203040506070
Voltage (Volts)
Current (Amp)
50HZ
60HZ
4 kW Models
6 kW Single−Phase
7.5 kW Three−Phase
7.5 kW Models
