THE INFORMATION IN THIS PAGE IS MEANT TO BE USED
BY A QUALIFIED MILLIPORE SERVICE REPRESENTATIVE
3
ASM installation
UV lamp
Before proceeding, make sure the ASM is not electrically
connected to the Water System.
The following procedure shows the installation of the UV lamp.
Step Action
1 Separate the ballast from the reservoir lid by removing the two
screws.
2 Connect the Ballast wires to the UV lamp by pushing the
connector onto the 4 pins of the UV Lamp.
3 Insert the UV lamp into the quartz sleeve.
Attention! Handle the UV lamp carefully. Use gloves.
4 Secure the ballast to the reservoir lid with the two screws.
Continued on next page
!
