INTERCONNECTION
SYSTEM DIAGRAM
Maximum system capability. Not all components or their maximum
quantity may be required.
INSTALLING THE TRANSDUCER
Refer to transducer manual for wiring details
Basic Wiring
black
white /
shield
Differential Level - Basic Wiring
transducer
#2
transducer
#1
white /
shield
black
white /
shield
MultiRanger Plus
customer
device
Milltronics TS-3,
temperature sensor
(optional)
Milltronics
transducer,see
Specifications
customer alarm,
pump or control
device
mA output
relay output
PL-513 14
