Electrical Manual
VM16,17,24,25,30 Electronic Orient Spindle
SERVING YOUR METAL CUTTING NEEDS FOR MORE THAN 25 YEARS
MC5 2011
Parameter Name 15/10 HP Unit
6422
CONSTANTS
P1-02 Frequency Width 6.0 Hz
P1-03 Ansback Det Time 0.50 Sec
P1-04 Wye Winding Sel 1
P1-05 CASE Param 5 .01
ELECTRONIC
ORIENT
CONSTANTS
P3-01** Orient Position 0 to 4095
P3-02 Position Gain H 20
P3-05 Ore Set Pulse 10
P3-06 Ore Reset Pulse 10
P3-07* Orient Speed 150
P3-08 Gear Ratio 1
P3-11 Gear Direction 0
P3-12 Dither Level 0
* Parameters will vary depending on RPM option of machine (See Chart Below)
** Orient Position will vary on every machine.
This listing contains the spindle drive parameters that have been changed by Milltronics
Manufacturing. All other parameters remain unchanged and are the factory default
settings from Yaskawa.
Constant Name 6K RPM 8K RPM 12K RPM
C1-01* Accel Time 1 1.5 1.5 1.5
C1-02* Decel Time 1 .4 8. 5.5
C1-03* Accel Time 2 .2 .2 .2
C1-04* Decel Time 2 .2 .2 225.2
C5-01* ASR P Gain 70 70. 70
C5-02* ASR I Gain .1 .1 .1
C5-03* ASR P Gain 2 80. 80. 80
C5-04* ASR I Time 2 .3 .3 .5
E1-04* Max Frequency 200. 266.7 200.
P3-07* Orient Speed 150. 400. 150.
Please consult Milltronics Service Department for current parameters.
28 Rev.9
