Milnor 42026X7J User Manual

Drain Valve Installation
PELLERIN MILNOR CORPORATION
Table 1: Parts List—Drain Valve Installation
Find the assembly for your machine and the letter shown in the "Item" column. The components for your
machine will show this letter or the word "all" in the "Used In" column. The numbers shown in the "Item"
column are those shown in the illustrations.
Used In Item Part Number Description/Nomenclature Comments
Assemblies
A GVD3626X7 Installation Group, 3626X 36026X8J,X8W,X8R
B GVD4226X Installation Group, 4226X7Z 42026X7J,X7W,X7R
42032X7J,X7W,X7R
Components
all 1 02 03245 Hose
all 2 96D350A71 Drain valve, 3", 240V 50/60C
all 3 96D35C0V Cover
all 4 02 02934A Bracket
A 5 02 13534 Bracket
B 5 02 23534 Bracket
all 6 27A088S Clamp, 3+1/16-4"
all 7 60B075 Hose
all 8 15N110H Bolt, M6-1X25MM
all 9 15G004HC Nut, M6-1, 3.5-6.5MM
all 10 15K039 Bolt, 1/4-20X3/4
all 11 15U185 Washer, 1/4"
all 12 15G178 Nut, 1/4"-20
all 13 15K095 Bolt, 3/8-16X1
all 14 15U240 Washer, 3/8"
all 15 15G198 Nut, 3/8-16
— End of BIMXCM13 —
