00A GCM33001A 90281Z COIN ASSY INSTALL 240V REFERENCE INSTALLATION COIN MACHINES
00B ACM33001A 90281Z*COIN ASSY 240V CONTAINS ITEMS 1-9
00C 38C062M 91237B*COIN INSERT ASSEMBLY US25 CONTAINS ITEMS 10-13
00D A33 08500 85443C COIN BOX ASSY-13.5"LONG CONTAINS ITEMS 14-16
00E SA 33 068 84507B$ COINREJECTOR ASS=NEW CAN.25 CONTAINS ITEMS 18B,19-20
001 02 03761 90012C COIN REJECTOR BRKT SUPT 3621
002 03 01472 76457B BRACKET=COIN SW ACTUATOR
003 03 01473B 89293D BRKT=COIN REJECTOR MTG SLIM
004 02 03348B 85324C GUIDE=COINCHUTE-CAD SLIME
005 02 03759 85324B CLIP FOR COIN REJECTOR
006 38C058 02Z ROTARY COIN SW CHERRY #E51-98R
007 38C071 03Z ELECMAGNT 240V60C #CR15-1100F
008 38C056 75729C WIRE=ROTARY SW-US.25 COIN
009 17B002 EXT.RET RING 6100-12-ST-PA
010 38C062J 85324B PLATE+SCAVENGING P/N ASSY
011 38C062A 78342B SCAVENGING PIN
012 38C062D 78342B SCAVENGING PIN SPRING
013 17B005 EXTRETRING IND#1000-X18-ST-ZD ZINC
014 W2 03654 89527C* BOX=13.5"X12DEG=COIN WELD
015 38C152A 10Z LOCK+2KEY CONSEC NO.15+1/8"LG
017 02 03761A 91047C REAR SUPT=COIN REJECTOR BKT
018A 38C050AMET METAL COIN ACCEPTOR 25J (COIN-MECH) CONTAINS ITEMS 19-20
018B 38C049A REJECTOR NEW CANADA 25J SEE SA33-68 OPT CANADIAN COIN REJECT
019 02 03302A 87211B INSERT CRANK =SLIMLINE
020 02 03361 68020A CRANKWASHER CADPLATE
021 X2 03363 87262A COIN RETURN RECEPTACLE
******** END OF PARTS LIST ********
How to Read Parts List
Reference Item Numbers
—Items 00A, 00B,
00C, etc., or 00X, 00Y, 00Z, etc., appearing at the top of
some parts lists, are for reference and provide:
1. The part number for the entire assembly depicted in
the drawing or a major sub-assembly thereof, and/or
2. The range of machine models this drawing applies to.
If more than one reference item appears, this usually
means this drawing applies to more than one assembly (and
thus to more than one range of machines).
Component Item Numbers
—For any item on
the drawing (e.g., item ➀), there may be several corre-
sponding items on the parts list (e.g., 001A, 001B, 001C,
etc.) which are similar components on different assemblies.
“How Part Is Used In Assembly” identifies which compo-
nents apply to your machine, by listing either the machine
model, or the reference item number from the top of the
parts list (e.g., 00A, 00B, 00C, etc.), or a particular charac-
teristic (e.g., bronze or stainless steel), or special ordering
information, such as a repair kit number.
BMP920010/97281V (Page 2)
COIN ASSEMBLY INSTALLATION-240V
30015, 30020 & 30022 COIN MACHINES
