00A SA 33 058K 94091D ASSY=SH MNT PERSTL SDINLT HS REFERENCE ASSEMBLY
001 W2 03589Y 94121D*WLMT=SH MT PERSTL NPT SDINLT
002 5SP0KXFHS 01Z HEX HEAD PIPE PLUG 1/2"
003 20C040 SIL SEAL RTV BLACK 85GR #59330
004 B2TAG89067 94146V SYS7 CHEM INJ INST & LOC
005 02 03304A 90493C GASKET=SOAP CHUTE 1/8"EPDM
006 02 03589J 89183C TAP PLATE=PERISTALTIC SUPPLY
007 24G018N ROLLED WASHER .194"ID NYLTITE #10W
008 15P010 12Z PHILPAN TRDCUTSCRTYP10-24X1/2SS
******** END OF PARTS LIST ********
How to Read Parts List
Reference Item Numbers
—Items 00A, 00B,
00C, etc., or 00X, 00Y, 00Z, etc., appearing at the top of
some parts lists, are for reference and provide:
1. The part number for the entire assembly depicted in
the drawing or a major sub-assembly thereof, and/or
2. The range of machine models this drawing applies to.
If more than one reference item appears, this usually
means this drawing applies to more than one assembly (and
thus to more than one range of machines).
Component Item Numbers
—For any item on
the drawing (e.g., item ➀), there may be several corre-
sponding items on the parts list (e.g., 001A, 001B, 001C,
etc.) which are similar components on different assemblies.
“How Part Is Used In Assembly” identifies which compo-
nents apply to your machine, by listing either the machine
model, or the reference item number from the top of the
parts list (e.g., 00A, 00B, 00C, etc.), or a particular charac-
teristic (e.g., bronze or stainless steel), or special ordering
information, such as a repair kit number.
BMP940077/94286V (Page 2)
LIQUID SUPPLY INLET SIDE MOUNT
