00A AD 33 011D 92426# FILL TUBE & DRAIN ASSY 240V REFERENCE-STANDARD ALL
00B AWS33001B 89241D*ASSY=3FLUSH SUP INJ SYSTEM 7 REFERENCE-3 FLUSH SUPPLY
00C SA 02 039D 91017# PIPING/5FLSHSUP=30"UNI(240V) REFERENCE-5 FLUSH SUPPLY
00D AVW33001 81482B*PRESSGUAGE+REGULATOR ASSY CM REFERENCE-5 FLUSH SUPPLY
00E SA 14 039 75627B* PRESSGAGE,FLUSHSUP 30+36 00D(CONTAINS 006&007)
00F SA 33 054A 91107B*INLET ASSY=CLDN M4567J/P CWM REFERENCE-COOLDOWN
00G A33 10700A 90482#*STEAM INLET ASSY 120V60C+ REFER-STEAM 3015/3020MXP
00H A33 10700B 90482# STEAM INLET ASSY 240V50/60 REFER-STEAM 3015/3020MXJ
00J A33 01200 91221C* ASSY WATERIN ONE 1" BALVALV REFER-AIR OPERATED WATER
00K AVW33002 92126M ASSY=FLOWMETER 3015/3020MXP REFERENCE-LIQUOR FLOW
001 09N086A 05Z PRESS SWITCH EATON #738-761 00A
002 96P016A71 05Z 1/2" DUOVAL 240V HAYS3108-6121 00A
003 96P013B71 04Z 3/4" 2WAY PLASTIC VALVE 240V60C 00B
004 96TBC2AA71 03Z 1/4" N/C 2WAY 240V50/60C 00C
005 96J030D 01Z 1/2" PRESREGULTR SET 28# FEM-UN 00D
006 30N100 07Z PRESSGUAGE 1/8"BACKCONN 0-30PSI PART OF 00E
007 96M001 02Z 1/2" X 3/8" RELIEF VAL. SET 31# PART OF 00E
008 51T025 01Z Y-STRAINER 1/2" CAST IRON 00F,00G,00H
009 96D034 04Z BALLVALVE 1/2" WATTS #6400-SS 00F
010 96TDC2AA71 04Z 1/2" N/C 2WAY 240V50/60C VALVE 00F
011 96M021 1/2"VACBREAK
012A 96P039A37 01Z 1/2"STEMVALVE 120V50/60C 150PSI 00G
012B 96P039A71 01Z 1/2" STEMVALVE 240V50/60 150PSI 00H
013 96D085BCSR 93513S 1.00WAT BVAL+ACT/BR/NC/ST/RH 00J
014 96D350A71 07Z DRAINVAL 3"MTRDRIVE 240V 50/60C 00A
015 30F515 FLOW SENSOR SIGNET P51530-P0 00K
******** END OF PARTS LIST ********
How to Read Parts List
Reference Item Numbers
—Items 00A, 00B,
00C, etc., or 00X, 00Y, 00Z, etc., appearing at the top of
some parts lists, are for reference and provide:
1. The part number for the entire assembly depicted in
the drawing or a major sub-assembly thereof, and/or
2. The range of machine models this drawing applies to.
If more than one reference item appears, this usually
means this drawing applies to more than one assembly (and
thus to more than one range of machines).
Component Item Numbers
—For any item on
the drawing (e.g., item ➀), there may be several corre-
sponding items on the parts list (e.g., 001A, 001B, 001C,
etc.) which are similar components on different assemblies.
“How Part Is Used In Assembly” identifies which compo-
nents apply to your machine, by listing either the machine
model, or the reference item number from the top of the
parts list (e.g., 00A, 00B, 00C, etc.), or a particular charac-
teristic (e.g., bronze or stainless steel), or special ordering
information, such as a repair kit number.
BMP920015/96132V (Page 2)
WATER / STEAM / DRAIN SCHEMATICS
30015,30020 & 30022 RIGID MOUNT WASHER-EXTRACTORS
