Illustration Explanation Illustration Explanation
Install the appropriate part here before
operating the machine.
During drain and extract, the cylinder must
rotate counterclockwise when viewed from
here.
Do not strike shell front of washer-extractors
during fork lifting. Striking shell front will
cause door to leak.
This is the hot water inlet.
7\_ccQbi _V DQW 9\\ecdbQdY_^c±
=Cdi\U GQcXUb5hdbQSd_bc =C9EE=D715)$$)3F " "
