Milnor C Series Service Manual

Ï
All values in foot pounds and (Newton meters)
Nominal
bolt size
Grade Designation
and Standard
Zinc or
Cadmium
Plated
If instructions call for:
Loctite
222 or
262
Loctite
242
Loctite
271
Loctite
272
Loctite
277
Bare
5/8 - 18 SAE Grade 1
ASTM A307
49.5
(67.11)
59.4
(80.54)
66.0
(89.48)
72.6
(98.43)
92.4
(125.27)
85.8
(116.33)
66.0
(89.48)
SAE Grade 2 82.6
(112.00)
99.1
(134.36)
110.2
(149.41)
121.2
(164.33)
154.2
(209.07)
143.2
(194.15)
110.2
(149.41)
SAE Grade 4 97.3
(131.92)
116.7
(158.22)
129.7
(175.85)
142.7
(193.48)
181.6
(246.22)
168.6
(228.59)
129.7
(175.85)
SAE Grade 5
ASTM A449
127.7
(173.14)
153.3
(207.85)
170.3
(230.90)
187.3
(253.95)
238.4
(323.23)
221.4
(300.18)
170.3
(230.90)
SAE Grade 7 157.6
(213.68)
189.1
(256.39)
210.2
(285.00)
231.2
(313.47)
294.2
(398.88)
273.2
(370.41)
210.2
(285.00)
SAE Grade 8
ASTM A354 Grade
BD
179.9
(243.91)
215.9
(292.72)
239.8
(325.13)
263.8
(357.66)
335.8
(455.28)
311.8
(422.74)
239.8
(325.13)
ASTM A354 Grade
BC
———————
Ï
All values in foot pounds and (Newton meters)
Nominal
bolt size
Grade Designation
and Standard
Zinc or
Cadmium
Plated
If instructions call for:
Loctite
222 or
262
Loctite
242
Loctite
271
Loctite
272
Loctite
277
Bare
3/4 - 10 SAE Grade 1
ASTM A307
77
(104.40)
93
(126.09)
103.1
(139.78)
113
(153.20)
144
(195.24)
134
(181.68)
103
(139.65)
SAE Grade 2 129.4
(175.44)
155.3
(210.55)
172.5
(233.88)
189.8
(257.33)
241.5
(327.43)
224.3
(304.11)
172.5
(233.88)
SAE Grade 4 152.6
(206.90)
183.1
(248.25)
203.4
(275.77)
223.8
(303.43)
284.8
(386.14)
264.5
(358.61)
203.4
(275.77)
SAE Grade 5
ASTM A449
199.7
(270.76)
239.6
(324.85)
266.3
(361.05)
292.9
(397.12)
372.8
(505.45)
346.1
(469.25)
266.3
(361.05)
SAE Grade 7 246.8
(334.62)
296.2
(401.60)
329.1
(446.20)
362.0
(355.22)
460.7
(624.63)
427.8
(580.02)
329.1
(446.20)
SAE Grade 8
ASTM A354 Grade
BD
282.0
(382.34)
338.3
(458.67)
375.9
(509.65)
413.5
(560.63)
526.3
(713.57)
488.7
(662.59)
375.9
(509.65)
ASTM A354 Grade
BC
246.4
(334.07)
295.7
(400.92)
328.6
(445.53)
361.5
(490.13)
460.0
(623.67)
427.2
(579.20)
328.6
(445.53)
MSSM0101CE/9906AV (10 of 19)
