Milnor C Series Service Manual

Ï
All values in foot pounds and (Newton meters)
Nominal
bolt size
Grade Designation
and Standard
Zinc or
Cadmium
Plated
If instructions call for:
Loctite
222 or
262
Loctite
242
Loctite
271
Loctite
272
Loctite
277
Bare
7/8 - 14 SAE Grade 1
ASTM A307
137.8
(186.83)
165.4
(224.25)
183.8
(249.20)
202.1
(274.01)
257.3
(348.85)
238.9
(323.90)
183.8
(249.20)
SAE Grade 2 137.8
(186.83)
165.4
(224.25)
183.8
(249.20)
202.1
(274.01)
257.3
(348.85)
238.9
(323.90)
183.8
(249.20)
SAE Grade 4 271.5
(368.11)
325.8
(441.73)
362.0
(490.80)
398.2
(539.89)
506.8
(687.13)
470.6
(638.05)
362.0
(490.80)
SAE Grade 5
ASTM A449
355.2
(481.59)
426.2
(577.85)
473.6
(642.12)
521.0
(706.38)
663.0
(898.91)
615.7
(834.78)
473.6
(642.12)
SAE Grade 7 438.0
(593.85)
525.7
(712.75)
584.1
(791.93)
642.5
(871.11)
817.7
(1108.65)
759.3
(1029.47)
584.1
(791.93)
SAE Grade 8
ASTM A354 Grade
BD
501.2
(679.54)
601.5
(815.53)
668.3
(906.09)
735.1
(996.66)
935.6
(1268.50)
868.8
(1177.94)
668.3
(906.09)
ASTM A354 Grade
BC
———————
Ï
All values in foot pounds and (Newton meters)
Nominal
bolt size
Grade Designation
and Standard
Zinc or
Cadmium
Plated
If instructions call for:
Loctite
222 or
262
Loctite
242
Loctite
271
Loctite
272
Loctite
277
Bare
1 - 8 SAE Grade 1
ASTM A307
187.5
(254.22)
225.0
(305.06)
250.0
(338.95)
275.0
(372.85)
350.0
(474.54)
325.0
(440.64)
250.0
(338.95)
SAE Grade 2 187.5
(254.22)
225.0
(305.06)
250.0
(338.95)
275.0
(372.85)
350.0
(474.54)
325.0
(440.64)
250.0
(338.95)
SAE Grade 4 369.4
(500.84)
443.3
(601.03)
492.5
(667.74)
541.8
(734.58)
689.5
(934.84)
640.3
(868.13)
492.5
(667.74)
SAE Grade 5
ASTM A449
482.8
(654.59)
579.4
(785.56)
643.8
(872.88)
708.1
(960.05)
901.3
(1222.00)
836.9
(1134.69)
643.8
(872.88)
SAE Grade 7 596.3
(808.47)
715.5
(970.09)
795.0
(1077.88)
874.5
(1185.66)
1113.0
(1509.03)
1033.5
(1401.24)
795.0
(1077.88)
SAE Grade 8
ASTM A354 Grade
BD
681.6
(924.13)
817.9
(1108.92)
908.8
(1232.17)
999.6
(1355.28)
1272.3
(1725.00)
1181.4
(1601.77)
908.8
(1232.17)
ASTM A354 Grade
BC
596.7
(809.01)
716.1
(970.90)
795.6
(1078.69)
875.2
(1186.61)
1113.9
(1510.25)
1034.3
(1402.32)
795.6
(1078.69)
MSSM0101CE/9906AV (12 of 19)
