Milnor C Series Service Manual

Ï
All values in foot pounds and (Newton meters)
Nominal
bolt size
Grade Designation
and Standard
Zinc or
Cadmium
Plated
If instructions call for :
Loctite
222 or
262
Loctite
242
Loctite
271
Loctite
272
Loctite
277
Bare
1-3/8 • 6 SAE Grade 1
ASTM A307
491.1
(665.84)
589.4
(799.12)
654.8
(887.79)
720.3
(976.60)
916.8
(1243.00)
851.3
(1154.21)
654.8
(887.80)
SAE Grade 2 491.1
(665.84)
589.4
(799.12)
654.8
(887.79)
720.3
(976.60)
916.8
(1243.00)
851.3
(1154.21)
654.8
(887.80)
SAE Grade 4 968.1
(1312.57)
1161.7
(1575.06)
1290.8
(1750.10)
1419.9
(1925.13)
1807.1
(2450.10)
1678.0
(2275.07)
1290.8
(1750.09)
SAE Grade 5
ASTM A449
1102.1
(1494.25)
1322.6
(1793.20)
1469.5
(1992.38)
1616.5
(2191.68)
2057.3
(2789.33)
1910.4
(2590.16)
1469.5
(1992.38)
SAE Grade 7 1563.6
(2119.96)
1876.4
(2544.06)
2084.8
(2826.61)
2293.3
(3109.30)
2918.8
(3957.37)
2710.3
(3674.68)
2084.8
(2826.61)
SAE Grade 8
ASTM A354 Grade
BD
1786.6
(2422.30)
2144.0
(2906.88)
2382.2
(3229.83)
2620.4
(3552.79)
3335.1
(4521.80)
3096.8
(4198.70)
2382.2
(3229.83)
ASTM A354 Grade
BC
1563.6
(2119.96)
1876.4
(2544.06)
2084.8
(2826.61)
2293.3
(3109.30)
2918.8
(3957.37)
2710.3
(3674.68)
2084.8
(2826.61)
Ï
All values in foot pounds and (Newton meters)
Nominal
bolt size
Grade
Designation and
Standard
Zinc or
Cadmium
Plated
If instructions call for :
Loctite
222 or
262
Loctite
242
Loctite
271
Loctite
272
Loctite
277
Bare
1-3/8 • 12 SAE Grade 1
ASTM A307
559.5
(758.58)
671.3
(910.16)
745.9
(1011.30)
820.5
(1112.45)
1044.3
(1415.88)
969.7
(1314.74)
745.9
(1011.30)
SAE Grade 2 559.5
(758.58)
671.3
(910.16)
745.9
(1011.30)
820.5
(1112.45)
1044.3
(1415.88)
969.7
(1314.74)
745.9
(1011.30)
SAE Grade 4 1102.1
(1494.25)
1322.6
(1793.21)
1469.5
(1992.38)
1616.5
(2191.68)
2057.3
(2789.33)
1910.4
(2590.16)
1469.5
(1992.38)
SAE Grade 5
ASTM A449
1254.3
(1700.60)
1505.1
(2040.64)
1672.3
(2267.34)
1839.6
(2494.16)
2341.3
(3174.38)
2174.0
(2947.55)
1672.3
(2267.34)
SAE Grade 7 1780.2
(2413.63)
2136.2
(2896.30)
2373.6
(3218.17)
2611.0
(3540.04)
3323.0
(4505.39)
3085.7
(4183.65)
2373.6
(3218.17)
SAE Grade 8
ASTM A354
Grade BD
2034.1
(2757.87)
2441.0
(3309.56)
2712.2
(3677.25)
2983.4
(4044.95)
3797.1
(5148.18)
3525.8
(4780.35)
2712.2
(3677.25)
ASTM A354
Grade BC
— ——————
MSSM0101CE/9906AV (16 of 19)
