ËMain Drive and Centrifugal Switch Belt Pulleys For Single Motor Drive
See FIGURE 5 during the following procedures:
1. Stretch a string from the motor pulley to the main drive pully as shown on FIGURE 5.
2. Adjust the position of the main drive pulley until the string touches A, B, C, and D. Secure the main drive
pully.
ËExtract, Main Drive, and Centrifugal Switch Belt Pulleys For Dual Motor Drive
See FIGURE 5 during the following procedures:
1. Stretch a string from the Extract Clutch on E2/Drain (large) motor to the pulley on the jackshaft as shown on
FIGURE 5.
2. Adjust the position of the jackshaft pulley until the string touches A, B, C, and D. Secure the jackshaft pulley.
3. Check the main drive pulley for alignment with the jackshaft pulley. Stretch a string from the jackshaft pulley
to the main drive pulley.
4. Adjust the main drive pulley position if necessary. Now check the centrifugal switch pulley (M4P, M5P,
M6P, and M7P models only) alignment.
CRUSH AND ENTANGLE HAZARD—Belts and pulleys can crush and entangle
body parts.
☞ Insure belt and pulley guards are in place before operating machine.
ËTesting Belt Alignment
—After aligning the belts, observe the belts with the machine operating. If an ad-
justment is necessary, lock OFF and tag out power before proceeding.
