Milnor C Series Service Manual

R
Pellerin Milnor CorporationPellerin Milnor Corporation
P. O. Box 400, Kenner, LA 70063-0400
Litho in U.S.A.
Item
Part Number
Description
Comments
Used In
Find the correct assembly first, then find the needed components. The item letters (A, B, C, etc.) assigned to assemblies are referred to in the "Used In" column to identify which components belong to an assembly. The item numbers (1, 2, 3, etc.) assigned to components relate the parts list to the illustration.
Item
Part Number
Description
Comments
Used In
Parts List, cont.—Drive Chart
Parts List—Drive Chart
BMP910031/98373V
(Sheet 2 of 3)
. ---------------------------------------------------------------------ASSEMBLIES------------------------------------------------------------------
A D33 01150 *DRIVECHART=C6M 50CYC 50C-3015M6P B D33 01160 *DRIVECHART=C6M 60CYC 60C-3015M6P C D33 01250 *DRIVECHART=C4M 50CYC 50C-3015M4P D D33 01260 *DRIVECHART=C4M 60CYC 60C-3015M4P E D33 01350 *DRIVECHART=CWE+3015N4S 50CYC 50C-3015M4A, C4A,
M4G, M4J, AND 3020C4A
F D33 01360 *DRIVECHART=CWE+3015N4S 60CYC 60C-3015M4A/G/J/T,
C4A/T, M6A/T AND
3020C4A, M4J
G D33 01450 *DRIVECHART=3020C5M 50CYC 50C-3020M5P H D33 01460 *DRIVECHART=3020C5M 60CYC 60C-3020/3022M5P J D33 01550 *DRIVECHART=3020N4S 50CYC 50C-3020M4A, M5G,
M5J, M5P
K D33 01560 *DRIVECHART=3020N4S 60CYC 60C-3020M4A, M5X,
AND 3022M4X, C5X
L D33 01650 *DRIVECHART=N6E 50 CYC 50C-3015M6G, M6J M D33 01660 *DRIVECHART=N6E 60CYC 60C-3015M6G, M6J N D33 01750 *DRIVECHART=N5E 50CYC 50C-3020M5G, M5J,
3022M5J
P D33 01760 *DRIVECHART=N5E 60CYC 60C-3020M5G, M5J
AND 3022M5X, M5G
-------------------------------------------------------------------COMPONENTS------------------------------------------------------------------ A, B, C, 1 56VA034X VBELT AX34 DAYCO RAWEDGE COG D, L, M G, H 1 56VA037X VBELT AX37 DAYCO RAWEDGE COG E, F 1 56VA035X VBELT AX35 DAYCO RAWEDGE COG A-F, L, 2 56VA035X VBELT AX35 DAYCO RAWEDGE COG M J, K, N, 2 56VA038X V-BELT AX38.1 RAWEDGE COG P G, H, J, 1 56VA038X V-BELT AX38.1 RAWEDGE COG K, N, P
G, H, J, 3 02 03624 VPUL=CLUTCH A2G8.5 K, N, P A-F, L, 4 54H160A CLUTCH 12VDC MA-7+3/8A-2G M G, H, J, 4 54H164A CLUTCH 12VDC MAPM02 K, N,P G, H, J, 5 15K041B SKCPSCR 1/4-20X1"BLK GR8 K, N, P G, H, J, 6 15U180 LOCKWASHER MEDIUM 1/4 ZINCPL K, N, P G, N 7 02 03623A VPUL=JACKSHFT A3G3.72A1G3.53 H, P 7 02 03623 VPUL=JACKSHAFT A3G3.1A1G3.53 J 7 02 03717 VPUL=JACKSHFT A3G3.72+A1G4.3 K 7 02 03716 VPUL=JACKSHAFT A3G3.1+A1G4.3 A, L 7 02 03552A VPUL=JACKSHFT A2G3.0+A1G2.80 B, M 7 C2 03552 VPUL=JACKSHFT A2G2.6+A1G2.96 C, E 7 02 03449A VPUL=JACKSHFT A2G3.12+A1G4.3 D, F 7 C2 03449 VPUL=JACKSHFT A2G2.6+A1G4.30 alL 8 15E210 SQMACHKEY 1/4X2 NOTAPER-NOHEAD alL 9 15Q072 SOKSETSCR CUP1/4-20X1/4BLKALLE A, C-H, 10 20C011C RETAIN CMPD 250CC LCT#609-41 J-N, P alL 10 56Q0MHS 627" BUSH VPUL TYPE H,D,OR QT A-D, G, 11 02 03656A VPUL=CENT SW W/2+1/8 PILOT H alL 12 56180A2SDA VPUL 2A18.0 (SD) TYPE QD CWE 3015-C4X, M4AGJT,
M6AGJT, BO22-C5X
alL 12 56180A2SDB VPUL 2A18.0(SD) BACKFACE CWM 3015-M4P, M6P alL 12 02 03625 PULLEY=FLATFACE 21.44PD CAST 3022-M4X, M5X A, B, G, 13 56Q1KP1 1+1/2" BUSH VPUL BROWNING P1 H, J, K, N, P C-F, L, 13 56Q1KSD 1+1/2" BUSH VPUL QD TYPE SD M A-D, G, 14 56V40470S FHP VBELT 4L470 A-SECTION H A-D, G, 15 56030A1H VPUL 1A3.0/L2.66 AK32H R EQUAL H A-D, G, 16 56Q0MHS 627" BUSH VPUL TYPE H,D,OR QT
