00A A33 08100 84173J*MOTOR MOUNT 3P C5M 30020M5P,M7P 3P+30022M5P
00B-1 A33 08100A 84173J*MOTOR MOUNT 3P N5E+N4S/3020 30020M5G/J,M7G/J,M4X(3P50C+3P60C24V&UNDER)
00B-2 A33 08100A 84173J*MOTOR MOUNT 3P N5E+N4S/3020 30022M4X,M5A,M5G,M5J,M5T
00C A33 08171 780632*MOTOR MOUNT 1P CWE+N4E+N4S1 30015M4A/G/J,C4A 1P
00D A33 08171A 89406N*MOTOR MOUNT 1PH CWM 30015M4P 1P
00E A33 08174 841731*MOTOR MOUNT 3P C4M 30015M4P 3P
00F A33 08174A 84173J*MOTOR MOUNT 3P C6M 30015M6P 3P
00G A33 08174B 84173J*MOTOR MOUNT=3P N6E 30015M6G/J 3P
00H-1 A33 08174C 84173J*MOTOR MOUNT 3P CWE+N4E+N4S1 30015M4A/G/J,C4A 3P+3020C4A,M4X(3P60C380V&UP)
00H-2 A33 08174C 84173J*MOTOR MOUNT 3P CWE+N4E+N4S1 30022C5A,C5T+30015M4T,C4T,M6A,M6T
001 02 03503A 84173D MOTOR MOUNT
002 02 03549 88427D MOTORMOUNT=E2 MOTOR
003 02 13156 72344A SPACER-MOTOR MOUNTING 00A,00E,00H
004 02 03551 83433B ADJROD=MOTOR (3/8-16X12")ZNC
005 02 03394 TEEROD=MTRMOUNT
006 02 03409 67413AADJ STRAP MTRMOUNT
007 60B065 RUBBER MOUNT CENTER BONDED 40 DURO
008A 60B055 01Z VIBRO ISOLATER REINFORCED 70 D 00A-00B,00F-00G
008B 60B070 01Z VIBRO-ISOLATOR REINFORCED 40 D 00C-00E,00H
009 12P1APSB SNAPBUSH .75MHX.627 T=.25HEYCO#2840
010 12P1ARSB SNAPBUSH 7/8MHX3/8 T=1/8 HEYCO#2110
011 12P1ARNB SHORTYBUSH 7/8MHX.75ID HEYCO #2850
******** END OF PARTS LIST ********
How to Read Parts List
Reference Item Numbers
—Items 00A, 00B,
00C, etc., or 00X, 00Y, 00Z, etc., appearing at the top of
some parts lists, are for reference and provide:
1. The part number for the entire assembly depicted in
the drawing or a major sub-assembly thereof, and/or
2. The range of machine models this drawing applies to.
If more than one reference item appears, this usually
means this drawing applies to more than one assembly (and
thus to more than one range of machines).
Component Item Numbers
—For any item on
the drawing (e.g., item ➀), there may be several corre-
sponding items on the parts list (e.g., 001A, 001B, 001C,
etc.) which are similar components on different assemblies.
“How Part Is Used In Assembly” identifies which compo-
nents apply to your machine, by listing either the machine
model, or the reference item number from the top of the
parts list (e.g., 00A, 00B, 00C, etc.), or a particular charac-
teristic (e.g., bronze or stainless steel), or special ordering
information, such as a repair kit number.
BMP920027/93251V (Page 2)
MOTOR MOUNT ASSEMBLY
30015, 30020 & 30022 RIGID MOUNT WASHER-EXTRACTORS
DRIVE ASSEMBLIES
