D01 17R022A08A THRD ROD 1/2-13UNCX8" LG ZN PL GR 2
D02 17W025 03Z SPHERICAL WASHER SET 9/16 M/F
D03 15U300 LOKWASHER REGULAR 1/2 ZINC PLT
D04 15G230 HXNUT 1/2-13UNC2B SAE ZINC GR2
D05 15K162 HXCAPSCR 1/2-13UNC2AX1.5 GR5 PLATED
D06 15G205 HXNUT 3/8-16UNC2B ZINC GR2
D07 15K095 SKSCR 3/8-16UNC2AX1"GR5 ZNC/CAD
D08 15U255 LOCKWASHER MEDIUM 3/8 ZINCPL
D09 02 03792B 93501C PIVOT BRKT SINGLE MTR TALL
D10 02 03791A 93201C MOTOR MOUNTING PLT SNGL MTR
D11 15U280 01Z FL+WASHER(USS STD)1/2 ZNC PL+D
D12 15U240 FLATWASHER(USS STD) 3/8" ZNC PLT
D13 15U241 FLATWASHER 13/32IDX1+3/4ODX14GA ZNC
******** END OF PARTS LIST ********
How to Read Parts List
Reference Item Numbers
—Items 00A, 00B,
00C, etc., or 00X, 00Y, 00Z, etc., appearing at the top of
some parts lists, are for reference and provide:
1. The part number for the entire assembly depicted in
the drawing or a major sub-assembly thereof, and/or
2. The range of machine models this drawing applies to.
If more than one reference item appears, this usually
means this drawing applies to more than one assembly (and
thus to more than one range of machines).
Component Item Numbers
—For any item on
the drawing (e.g., item ➀), there may be several corre-
sponding items on the parts list (e.g., 001A, 001B, 001C,
etc.) which are similar components on different assemblies.
“How Part Is Used In Assembly” identifies which compo-
nents apply to your machine, by listing either the machine
model, or the reference item number from the top of the
parts list (e.g., 00A, 00B, 00C, etc.), or a particular charac-
teristic (e.g., bronze or stainless steel), or special ordering
information, such as a repair kit number.
BMP950003/95107V (Page 2)
MOTOR MOUNT
30015 & 30020 S4A,S4G,S4J,S4T
To Next Page
