00A SA 13 013 85242D$ JKSHAFT ASSY DBLROW= 30020M4X,M5X,M7X+3022M4X,M5X
00B SA 33 034 85251D$ JKSHAFT ASSY SGLROW=CWE+C4 30015C4X,M4X,M6X+30020C4A,M4X+3022C5X
001 X2 03308 91212C HSG-JACKSHAFT=1/CWU+3626SWE
002 02 13163 92233D JACKSHAFT=3626SWE
003 17B135 EXT. RET RING 4000-200-ST-ZD
004 17B155 EXTERNAL RETAINING RING
006 54A070 BALLBEAR FAFNIR P205PP FA52908 1/BX
007A 54A926 BALLBEAR DOUBLE ROW TYPE 5206 00A (DOUBLE ROW BEARING)
007B 54A080 BALLBEAR FAFNIR P206PP FA52908 1/BX 00B (SINGLE ROW BEARING)
008 20C005C ADH/SEALANT 250 CC LOCTITE #271-41
******** END OF PARTS LIST ********
How to Read Parts List
Reference Item Numbers
—Items 00A, 00B, 00C, etc., or 00X, 00Y, 00Z, etc., appearing at the top of
some
parts lists, are for reference and provide:
1. The part number for the entire assembly depicted in the drawing or a major sub-assembly thereof, and/or
2. The range of machine models this drawing applies to.
If more than one reference item appears, this usually means this drawing applies to more than one assembly (and
thus to more than one range of machines).
Component Item Numbers
—For any item on the drawing (e.g., item
➀
), there may be several corresponding
items on the parts list (e.g., 001A, 001B, 001C, etc.) which are similar components on different assemblies. “How Part
Is Used In Assembly” identifies which components apply to your machine, by listing either the machine model, or the
BMP910035/93251V (Page 2)
JACKSHAFT ASSEMBLY
30015,30020 & 30022 RIGID MOUNT WASHER-EXTRACTORS
