00A G33 04000H 91477# CONDUIT+SHELLFT 3015/3020M4A REFERENCE
00C A33 10100H 91477# SHELL FRONT ASSY 3015/20M4A REFERENCE
00D A33 10100C 91477#*SHLASSY (IDNT) UNLOK N4P REFERENCE
001 X2 02361B 92567D SHELLFRONT,30",ELECTRIC LOCK
002 A33 07100C 91477#*DRASSY(INDNT)LK,LOGO N4,5,6P
003 EDL00171 88093# INTRLKHSG ASSY=N/UNLOCK 240V
004 01 10422 88302C NPLATE:DOOR ILOC-N4,5,6 P
005 12K040 1/2" COND.EMT CONDUIT PECO #260B
006 03 01446 87306B 1/2 EMT CONDUIT 900D=DR INTR
007 10Y71M4GEX 88466N*M4G EXTERNAL CONNECTIONS
008 12K040 1/2" COND.EMT CONDUIT PECO #260B
009 12P1ASSB SNAPBUSH 7/8MHX11/16 HEYCO #2126
010 15G200C 01Z HXCPNUT HI 3/8-16 BRASS NIK PLT
011 02 02819B 84383C SPACER HINGE S/S
012 02 02293 92601A DOOR HANDLE NUT GASKET
013 15K084 85196B TRUSS HXSOK 3/8-16 X 23/32SS
014 02 03669 92601A GASKET=INTRLK HOUSING
015 15N174 HXCAPSCR 1/4-20UNC2X5/8SS18-8
016 15U180 LOCKWASHER MEDIUM 1/4 ZINCPL
017 24G020N ROLLED WASHER .252"ID NYLTITE #25W
018 15G168 SQNUT 1/4-20UNC2 SS18-8
******** END OF PARTS LIST ********
How to Read Parts List
Reference Item Numbers
—Items 00A, 00B,
00C, etc., or 00X, 00Y, 00Z, etc., appearing at the top of
some
parts lists, are for reference and provide:
1. The part number for the entire assembly depicted in
the drawing or a major sub-assembly thereof, and/or
2. The range of machine models this drawing applies to.
If more than one reference item appears, this usually
means this drawing applies to more than one assembly (and
thus to more than one range of machines).
Component Item Numbers
—For any item on
the drawing (e.g., item
➀
), there may be several corre-
sponding items on the parts list (e.g., 001A, 001B, 001C,
etc.) which are similar components on different assemblies.
“How Part Is Used In Assembly” identifies which compo-
nents apply to your machine, by listing either the machine
model, or the reference item number from the top of the
parts list (e.g., 00A, 00B, 00C, etc.), or a particular charac-
teristic (e.g., bronze or stainless steel), or special ordering
information, such as a repair kit number.
BMP920024/93251V (Page 2)
SHELLFRONT ASSEMBLY, CONDUIT & INTERLOCK INSTALLATION
30015, 30020 & 30022 RIGID MOUNT WASHER-EXTRACTORS
