Item

Part Number

Description

Comments

Used In

Find the correct assembly first, then find the needed components. The item letters (A, B, C, etc.) assigned to assemblies are referred to in the

"Used In" column to identify which components belong to an assembly. The item numbers (1, 2, 3, etc.) assigned to components relate the

parts list to the illustration.

Parts List—Frame Pivots and Tilt Stops

PELLERIN MILNOR CORPORATION

---------------------------------------------------------------------------------------------ASSEMBLIES--------------------------------------------------------------------

A GHF68004 6836M5K FRAMES+PIVOT INSTALL 68036M5K

B GHF72001 7246M5K FRAMES+PIVOT INSTALL 72046M5K

C GHF48007 4840M7K HYD TILT 2-WAY 48040M7K

--------------------------------------------------------------------------------------------COMPONENTS------------------------------------------------------------------

all 1 X2 22655 6836M5K BALLBUSH HOUSING

all 2 02 22659 6836M5K TILT FRAME PIVOT BRACKET

all 3 54A707 SPHERICAL PLAIN BRG BALL BUSHING 3" RBC# B48-L

all 4 56AHW114 TW114 BEARING LOCWASHER

all 5 56ATW14 TONGUE WASH TIM K91514 FOR N14

all 6 56AHN14 N14 BEARING LOCKNUT

all 7 W2 22659A 6836M5K TILT FRAME SHAFT SUPPT WLMT

all 8 02 22659B 6836M5K TILT FRAME SHAFT SUPPT 16GA SHIM

all 9 54M025 HYDFIT 1/8"-90 ALEMITE 1613-B

AB 10 02 22680 MD6836M5K TILT FRAME REAR STOP BRKT

all 11 02 22680A 6836M5K TILT STOP DOUBLER

all 12 02 22734 6836M5K TILT FRAME REAR STOP RESTPAD
