How To Use the Red Safety Support(s) for Maintenance
What Safety Supports are Provided and Why
These machines are provided with two safety stands that can be folded down from within a
channel that is part of the shell weldment when the machine is in the wash position. If the
machine has an automatic loading elbow (dryel), it is provided with a safety bar that can be
inserted when the dryel is up.
Use the safety support(s) whenever the maintenance to be performed requires you to place any
part of your body in or near the path of the vertically moving portion of the machine. When not in
use, stow the safety supports as explained herein.
Figure 1: Safety Stands for Rubber Spring-resting, Hydraulic-tilt Washer-extractor Models (stowed
shown at top, deployed shown at bottom)
