How To Use the Red Safety Support(s) for Maintenance
PELLERIN MILNOR CORPORATION
Figure 2: Safety Bar for Rubber Spring-resting, Hydraulic-tilt Washer-extractor Models with a Dryel
WARNING
1 : Crush Hazard—The safety supports provide protection against the drifting
down of the vertically moving po
rtion of the machine during maintenance in the event of a leak
in the hydraulic system. They are not intended to restrain the machine from coming down under
power.
Never work in or near the path of the vertically moving portion of the machine unless the
safety supports are deployed and power is locked out/tagged out.
Do not attempt to rest the safety stands on the floor by tilting the machine back under
power.
Maintain the safety support(s) in good condition.
Where a pair of safety supports is provided, always use both safety supports.
When not in use, stow these safety components in the location provided on the machine.
2.
How to Deploy the Safety Support(s)
2.1.
Put the Machine In Position to Accept the Safety Support(s)—At the controls,
put the machine in the wash position (the shell is horizontal).
2.2.
Put the Safety Support(s) in Position—Lower the safety stands from within the
channel as follows:
1. Remove the cotter pins from all six retaining pins.
13
