Item
Part Number
Description
Comments
Used In
Find the correct assembly first, then find the needed components. The item letters (A, B, C, etc.) assigned to assemblies are referred to in the
"Used In" column to identify which components belong to an assembly. The item numbers (1, 2, 3, etc.) assigned to components relate the
parts list to the illustration.
Parts List—48” Hydraulic Door Components
---------------------------------------------------------------------------------------------ASSEMBLIES--------------------------------------------------------------------
A GHT68001 INST=HYD MTR/TORQARM RH-6836 68036H5N, 68036H5K
B GHT68005 6836M5K HYD MTR/TORQARM 68036M5K, 72046M5K
--------------------------------------------------------------------------------------------COMPONENTS------------------------------------------------------------------
all 1 27E320025 TDRQMOTOR- HYDRAULIC
all 2 15K151 HXCAPSCR 1/2-13UNC24X1.25 GR5
all 3 15U280 FL+WASHER(USS STD)1/2 ZNC PL+D
all 4 15U300 LOKWASHER REGULAR 1/2 ZINC PLT
A 5 03 60789 AUTODOOR HYD MNT BRKT RH-6836
B 5 02 22716 6836M5K AUTODOOR HYD MNT BRKT
all 6 15K173A HXCAPSCR 1/2-13UNC2AX1.75 GR5
all 7 15U490 FLTWASH 1+1/2X17/32X1/4 ZINC
all 8 54N090 SPURGEAR B#YSS8-24 P1 PE-5064
all 9 56Q1AP1 1.0" BUSH VPUL BROWNING P1
all 10 54N095 SPURGR 8P80T20PA 1.5F YCS8P80
all 11 56Q1EP1 1+1/4" BUSH VPUL BROWNING P1
all 12 15E210 SQMACHKEY 1/4X2 NOTAPER-NOHEAD
all 13 54A718 FLGBRG 1+1/4" HC#FB150X1+1/4S
all 14 54M021 GRSFIT 1/8PIPE X 1/4STR 1607-B
all 15 15K088 HEXCAPSCR 3/8-16NCX7/8 GR 5 ZI
all 16 15U255 LOCKWASHER MEDIUM 3/8 ZINCPL
all 17 15G205 HXNUT 3/8-16UNC2B ZINC GR2
all 18 AGS75001L COVER=GEARTRAIN LH
all 19 15P185 TRDCUT-F HXHD 1/4-20UNC2AX3/4
all 20 15K162 HXCAPSCR 1/2-13UNC2AX1.5 GR5 P
all 21 W3 25328 WELD=TORQARM RH DOOR-6836
all 22 54AA00PBB BUSH BALL 3/4 RBC-B12L
all 23 03 25604 ADAPTER FOR B12-L BUSHING
all 24 60C075 TRUCK BUMPER 2+1/2ODW3/8HO.613
all 25 15K120 HXCAPSCR 3/8-16UNC2AX2 GR5 ZIN
all 26 15U240 FLATWASHER(USS STD) 3/8" ZNC P
all 27 15G218 HXLOKNUT NYL 3/8-16 STL/ZNC
A 29 52LY0ER001 HEXPIPNIP 1/4X1/4 #5404-4-4
A 30 52JY0ER003 ELB90 1/4"FEM.#5504-4-4
A 31 52XY0ER008 STRADAPT 1/4" #1404-4-4
A 32 60EH21C248 HYD HOSE 1/4" +2 X FORSW=248
B 32 60EH21C190 HYD HOSE=1/4" X 190”
.
Page (4 / 5)
48” Door Hydraulic Components
PELLERIN MILNOR CORPORATIONPELLERIN MILNOR CORPORATION
BMP120050/2015155A
68036H5N, 68036H5K, 68036M5K, 72046M5K
121
