-----------------------------------------------------------------------------------------ASSEMBLIES----------------------------------------------------------------------------
A AGS68001 6836M5K DRYEL FOLDING DOOR COVER ASSY
----------------------------------------------------------------------------------------COMPONENTS–------------------------------------------------------------------------
all 1 02 22529 DOOR TRACK ANGLE
all 2 W2 22530 WLMT=LOAD DOOR FIRST PANEL
all 3 04 24291 HINGE-SPRING OPEN 12GA 1/4"PIN
all 4 02 22533 CHUTE DOOR SECOND PANEL
all 5 02 22535 DOOR REST ANGLE
all 6 W2 22536 6836M5K DRYEL FOLDING DOOR LIFT WLMT
all 7 02 22537 DOOR GUIDE ROD BRKT
all 8 02 22822 6836M5K DRYEL BI-FOLD DOOR TRACK END
all 9 54E001C DRILLBUSHING FOR #80 CHAIN
all 10 60C001 RUBBER BUMPER-BLKW/WASHER #698
all 11 15K031 BUTSOKCAPSCR 1/4-20X1/2 SS18-8
all 12 15K041S HEXCAPSCR 1/4-20UNC2AX1 SS18-8
all 13 15K042L HXCAPSCR 1/4-20X1+1/4 SS
all 14 15K043 HXCAPSCR 1/4-20X1.5 GR5 ZINC
all 15 15U188 FLTWASH 1/4 STD COMM SS18-8
all 16 15U181 LOCKWASHER MEDIUM 1/4 SS18-8
all 17 15G170 HEXNUT 1/4-20UNC2 SS18-8
all 18 15K083V BUTSOKCAPSCR 3/8-16X3/4 SS18-8
all 19 15U260 LOCKWASHER MEDIUM 3/8 SS18-8
all 20 15G206 HEXNUT 3/8-16 UNC2 SS 18-8
all 21 15K086 HXCAPSCR 3/8-16NCX3/4 SS18-8
Page (x / x)Page (3 / 3)BMP150032/2015155A
DRYELL Folding Door
6836M5K, 7246M5K
Item
Part Number
Description
Comments
Used In
Find the correct assembly first, then find the needed components. The item letters (A, B, C, etc.) assigned to assemblies are referred to in the
"Used In" column to identify which components belong to an assembly. The item numbers (1, 2, 3, etc.) assigned to components relate the
parts list to the illustration.
Parts List—DRYELL Folding Door
PELLERIN MILNOR CORPORATION
139
