Item
Part Number
Description
Comments
Used In
Find the correct assembly first, then find the needed components. The item letters (A, B, C, etc.) assigned to assemblies are referred to in the
"Used In" column to identify which components belong to an assembly. The item numbers (1, 2, 3, etc.) assigned to components relate the
parts list to the illustration.
Parts List—Water
PELLERIN MILNOR CORPORATION
Page (x / x)Page (5 / 6)
Water
6836M5K, 7246M5K
-
---------------------------------------------------------------------------------------------ASSEMBLIES-------------------------------------------------------------------
A GVW68031 6836M5K STD H20 HOT/COLD/COOLDOWN
B AVW68031 6836M5K STD H20 HOT/COLD/COOLDOWN ASSY
C AVW68037 6836M5K DRYEL FLUSH ASSY
--------------------------------------------------------------------------------------------COMPONENTS------------------------------------------------------------------
All 1 27A062640A UNISTRUT 13/16HT X 40"LG
all 2 27A0200 CLP-RGDSTL PS#1100-2 10/BAG
all 3 15K085 HEXCAPSCR 3/8-16UNC2AX3/4 GR5
all 4 15U240 FLATWASHER(USS STD) 3/8" ZNC P
all 5 15G198 HXFLGNUT 3/8-16 ZINC
all 6 5P2AG4003K 2" X 3.5" SCH40 GALV" TOE/GOE
all 7 5SL2ANFA NPT ELBOW 90DEG 2" GALMAL 150#
all 8 5N2A04AG42 NPT NIP 2X4 TBE GALSTL SK40
all 9 5N2ACLSG42 NPT NIP 2XCLS TBE GALSTL SK40
all 10 5N2A37KG42 NPT NIP 2X37.5 TBE GALSTL SK40
all 10 5N2A58AG42 NPT NIP 2X58 TBE GALSTL SK40
all 11 5SL2ANFK NPTELB 45DEG 2"GALMAL 150#
all 12 51E098B KINGREDNIP2.5"IDX2"NPT#STC3025
all 13 5SCC2ANF NPT COUP 2" GALMAL 150#
all 14 5N2A06AG42 NPT NIP 2X6 TBE GALSTL SK40
all 15 5S2ANFA0P1 NPT TEE 2X2X3/4" GALMAL 150#
all 16 5N2A08AG42 NPT NIP 2X8 TBE GALSTL SK40
all 17 96D088FBA 2" BALVAL+ACT BRS N/C BONOMI
all 18 5S2ANFA NPT TEE 2" GALMAL 150#
all 19 51P060 PLUG PIPE SQ 2"GALCORED CI 125
all 20 27E971C VICT COUP 2"GALV #75W/E GASKET
all 21 5SB0P0KNFO NPTHEXBUSH 3/4X1/2 GALMAL 150#
all 22 5N0KCLSG42 NPT NIP 1/2XCLS TBE GALSTLSK40
all 23 96TDC2AA71 ½"N/C2WY240V50/60C VLV(DRYVC)
all 24 5N0P03AG42 NPT NIP 3/4X3 TBE GALSTL SK40
all 25 5SB0P0CNFA NPTHEXBUSH 3/4X1/8GALV150#CORD
all 26 30N100 PRESSGAUGE 1/8"BACKCN.0-30PSI
all 27 5S0KNFA NPT TEE 1/2" GALMAL 150#
all 28 5SL0KNFA NPTELB 90DEG 1/2 GALMAL 150#
all 29 51X017 UNIONSTRADT 1/2"#1404-8-8
all 30 5SP0PHFSS NPT PLUG 3/4 SQ SOLID STL/ZINC
BMP150033/2015292A
146
