Item
Part Number
Description
Comments
Used In
Find the correct assembly first, then find the needed components. The item letters (A, B, C, etc.) assigned to assemblies are referred to in the
"Used In" column to identify which components belong to an assembly. The item numbers (1, 2, 3, etc.) assigned to components relate the
parts list to the illustration.
Parts List—Single Drain Valve
---------------------------------------------------------------------ASSEMBLIES------------------------------------------------------------------
A GVD68001 INSTALL= 8"DUMPVAL 6836E
B AVD68001 ASSY= 8" DUMPVAL 6836E
C AD 15 090K INSTALL=AIR CHAMBER PRESS/SW
-------------------------------------------------------------------COMPONENTS------------------------------------------------------------------
all 1 SA 28 158 * BONNET+AIRCYL=8"SS DUMPVALV
all 2 02 18104 GASKET=8"DUMP VALVE BONNET
all 3 W2 18931 * BODY=8"DUMPVALV=4244,60,52
all 4 02 18068 9 SEAT-RESILIENT=8"DUMPVALVE
all 5 5SP0KGFSS NPT PLUG 1/2 SOSOLID GALSTL
all 6 53A047H MALCON 5/16X1/8POLY PH#68P-5-2
all 7 5SB0E0CBEO NPTHEXBUSH 1/4X1/8 BRASS 125#
all 8 5SR1A0ENF NPT RED 1X1/4 GALMAL 150#
all 9 5N1A05AG42 NPT NIPPLE 1X5 TBE GALSTL SK40
all 10 5SL1KNFACK NPTELB 90DEG 1X1/2 GALMAL 150#
all 11 5N0KCLSG42 NPT NIP 1/2XCLS TBE GALSTLSK40
all 12 24G030N ROLLED WASH.379ID NYLTITE 37W
all 13 15K086 HXCAPSCR 3/8-16NCX3/4 SS18-8
all 14 15U200 FLATWASHER(USS STD) 5/16"ZNC P
all 15 02 18107 GASKET=8"FLANGED DUMP VALVE
all 16 60E328A18A HOSE-8"1DX18"LONG TITAN ES115EX8000-18
all 17 27A092 HOSECLAMP S.S.SCR 7+1/8-10"
all 18 15K153 HXCAPSCR 1/2 -13X1+1/4SS
all 19 24G032N ROLLED WASH.500ID NYLTITE 50W
all 20 15U310 LOKWASHER REGULAR 1/2 SS18-8
all 21 15G225 HEXNUT 1/2-13UNC2 SS18-8
all 22 15K151 HXCAPSCR 1/2-13UNC24X1.25 GR5
all 23 15U300 LOKWASHER REGULAR 1/2 ZINC PLT
all 24 15G230 HXNUT 1/2-13UNC2B SAE ZINC Gr2
All 25 30R0043PB TEMPERATURE PROBE ASSY=BRASS
PELLERIN MILNOR CORPORATION
Page (2 / 2)BMP120048/2015155A
Single Drain Valve
68036H5N, 68036H5K, 68036M5K, 72046M5K
154
