Drain Valve Body with Two Valves
PELLERIN MILNOR CORPORATION
Table 1: Parts List—Dual drain valves
Find the assembly for your machine and the letter shown in the "Item" column. The components for your
machine will show this letter or the word "all" in the "Used In" column. The numbers shown in the "Item"
column are those shown in the illustrations.
Used In Item Part Number Description/Nomenclature Comments
Assemblies
A GVD68002 Installation Group, Drain valve body with two
valves
B AVD65003 Assembly, Drain valve body with two valves
Components
all 1 W2 18932E Weldment
all 2 02 18107 Gasket
all 3 15K151 Bolt, 1/2-13X1.25
all 4 15U300 Washer, Lock, 1/2
all 5 15G230 Nut, 1/2-13
all 6 SA 28 158 Bonnet
all 7 27A092 Hoseclamp, 7+1/8-10"
all 8 60E328A18A Hose, 8"X18"
all 11 02 18068 Seal
all 12 02 18104 Gasket, 8"
all 13 5SP0PBESC Plug, 3/4"
all 14 15K086 Bolt, 3/8-16X3/4
all 15 24G030N Washer, Nylon, .379
all 16 15U200 Washer, Flat, 5/16"
all 17 W3 25307D Tank
all 18 30N102 Pressure gage, 1/4", .0-150PSI
all 19 51V015 Tee, 1/4"
all 20 53A501 Flexible tubing, Adapter, 1/4"
all 21 53A500 Flexible tubing, Adapter, 1/4"
all 22 53A059A Flexible tubing, Adapter, 1/4"
all 23 53A007B Flexible tubing, Adapter, Female
thread.25X.25
all 24 60E004TE Flexible tubing, 1/4"
all 25 53A008B Flexible tubing, Adapter, Male thread,
.25X.25
all 26 96D047AAK Check valve, 1/4"
all 27 5SL0EBEC Elbow, 1/4
all 28 5SB0E0CBEO Hexbush, 1/4X1/8
all 29 96H018 Needle valve, 1/4" X 1/8
all 30 AD 15 090A Pressure switch
all 31 15K153 Bolt, Stainless Steel, 1/2-13X1+1/4
all 32 24G032N Washer, Nylon, .5
all 33 15U310 Washer, Lock, Stainless Steel, 1/2"
all 34 15G225 Nut, Stainless Steel, 1/2-13
— End of BIIFGM27 —
