Milnor MWF C Series Installation And Service

Bearing Housing Components and Installation: 68036F5N, 68036H5N, 68036H5K, 68036M5K, 72046M5K
PELLERIN MILNOR CORPORATION
Table 1: Parts List—Bearing Housing Components and Installation
Find the assembly for your machine and the letter shown in the "Item" column. The components for your
machine will show this letter or the word "all" in the "Used In" column. The numbers shown in the "Item"
column are those shown in the illustrations.
Used In Item Part Number Description/Nomenclature Comments
Assemblies
A GBM6836E Installation Group
B ABM6836E Assembly, Bearing housing
C ABM60010HS Assembly, Cylinder
D ABM60010SS Assembly, Seal, Front
E ABM6836EV Assembly, Bearing housing Viton Seal
F ABM60010HV Assembly, Cylinder Viton Seal
G ABM60010SV Assembly, Seal, Front Viton Seal
Components
all 1 X2 04390 Bearing housing
all 2 X2 04391 Shaft
all 3 X2 04392 Seal holder, Front
all 4 X2 04395 Seal holder, Rear
all 5 02 04393 Grease shield, Front
all 6 02 04394 Grease shield, Rear
all 7 02 04396 Seal holder
B 8 24S114 Seal 4.5X5.5X.50
E 8 24S114V Seal 4.5X5.5X.50, Viton
B 9 24S130 Seal 7.0X8.0X.625
E 9 24S130V Seal 7.0X8.0X.625, Viton
all 10 56AHN26 Bearing locknut
all 11 56AHW26 Bearing, Washer, Lock
all 12 56AHN34 Bearing locknut
all 13 56AHW34 Bearing, Washer, Lock
all 14 56S22326C3 Bearing
all 15 56S22334C4 Bearing
B 16 60C280 O-ring, 14.0X1/8
E 16 60C280V O-ring, 14.0X1/8, Viton
all 17 60C461 O-ring, 16.0X1/4
all 18 X2 21816 Key
all 19 X3 60084 Seal sleeve
all 20 15U181 Washer, 1/4 SS18-8
all 21 15N158 Bolt, 1/4-20NCX1/2SS18-8
all 22 15K095B Bolt, 3/8-16X1"
all 23 15U240L9 Washer, 3/8
all 24 15K095C Bolt, 3/8-16X1.25 GR 8 ZINC
all 25 15N091 Bolt, 8/32UNC2X1/2 S/S
all 26 02 04456 Piece part
all 27 X3 60085 Cover
all 28 03 60085A Gasket
all 29 15K086E Bolt, 3/8-16X3/4SS
all 30 X3 60089 Washer, Cylinder hub
74
