Item
Part Number
Description
Comments
Used In
Find the correct assembly first, then find the needed components. The item letters (A, B, C, etc.) assigned to assemblies are referred to in the
"Used In" column to identify which components belong to an assembly. The item numbers (1, 2, 3, etc.) assigned to components relate the
parts list to the illustration.
Parts List—Disc Brake
----------------------------------------------------------------------------------------------------ASSEMBLIES-------------------------------------------------------------------------------
A GBR6836E INST=DISC BRAKE 6836E M9V4840, M7V4836
68036F_, 68036H5_
B GBR68002 6836M5K DISC BRAKE 6836M5K
C GBR72001 7246M5K DISC BRAKE 7246M5K
D GBR48003 4840M7K DISC BRAKE INSTALL 48040M7K
--------------------------------------------------------------------------------------------------COMPONENTS-------------------------------------------------------------------------------
A,D 1 AAC4840F AIRCYL=BRAKE ASSY, 4840F7
B,C 1 AAC68001 AIRCYL=BRAKE ASSY, 6836F5A
all 2 02 22417 48M7 BRAKE+PROX MNT BRKT
all 3 W3 65238 *WLMT=MASTER BRAKE CYL BRKT
all 4 54KMC1125U MASTER CYLINDER
all 5 52XY0ER004 STRADTUN3/16MJX1/8FP#2405-3-2
all 6 54KC7961BG BRAKE HOSE=1/8"X18"OAL #50612
all 7 52AY0ER003 STR.1/4"MJICX1/8"MP#2404-4-2
A,C 8 X2 04454 MACH=BRK CALPR MNT PLT,6836
B 8 X2 04454A 6836M5K BRAKE CALIPER MOUNT PLATE
ABC 9 X2 04458 BRAKE ROTOR HUB-6836E
D 9 X2 21867 MACH=CALIPER DISK HUB,4840F
ABC 10 X2 04459 BRAKE ROTOR-6836E
D 10 X2 21866 MACH=CALIPER DISK, 4840F
all 12 15K095 HXCPSCR 3/8-16UNC2AX1 GR5 ZINC
all 13 15U255 LOCKWASHER MEDIUM 3/8 ZINCPL
all 14 15G205 HXNUT 3/8-16UNC2B ZINC GR2
all 15 15K151 HXCAPSCR 1/2-13UNC24X1.25 GR5
all 16 15U300 LOKWASHER REGULAR 1/2 ZINC PLT
all 17 15U490 FLTWASH 1+1/2X17/32X1/4 ZINC
all 18 15G230 HXNUT 1/2-13UNC2B SAE ZINC GR2
ABC 20 54KC7975 CALIPER HYD D/A 1/2"
D 20 54KC7974 CALIPER HYD D/A 3/8 DISC RETRACT.
all 22 15K214E HXCAPSCR 5/8-11UNC2AX1.5 GR5 Z
all 23 15U315 LOKWASHER MEDIUM 5/8 ZINCPL
all 24 15K155A SKCPSCR-1/2-13X1.5
all 25 15K086G HEXCAPSCR 3/8-24UNF X5" GRD. 8
ABC 26 56Q1RE 1+7/8" BUSH VPUL QD TYPE E
D 26 56Q1RSK 1+7/8" BUSH VPUL QD TYPE SK
all 27 27A031C UBOLT 1.25PIPE 5/16-18 ZINC
all 28 02 10539 SPACER FOR PIPE ZINC PLATED
all 29 02 175057 SPACER=BALLVALVE MTG
all 30 15U210 LOKWASHER MEDIUM 5/16 ZINCPL
all 31 15U200 FLATWASHER(USS STD) 5/16"ZNC P
all 32 15G196 HXFLGNUT 5/16-18 ZINC
all 33 54KC7961BSEAL SEAL WASHER CONICAL,BRAKE HOSE
PELLERIN MILNOR CORPORATION
Page (3 / 3)
M9V4840_, M7V4836_, 68036F_, 68036H5_, 48040M7K, 68036M5K, 72046M5K
Disc Brake
BMP120026/2015435A
92
