Pellerin Milnor Corporation
Find the assembly for your machine and the letter shown in the "Item" column. The components for your machine will show this
letter or the word "all" in the "Used In" column. The numbers shown in the "Item" column are those shown in the illustrations.
Used In Item Part Number Description/Nomenclature Comments
Assemblies
A 98MW3601 MAIN BEARING ASSY=MWF45 MWF45, Assembly, contains
items 30-55
B 98MW4201 MAIN BEARING ASSY=MWF77 MWF63 & MWF77, Assembly,
contains items 30-55
Components
A 1 98MW3601 MAIN BEARING ASSY=MWF45 Assembly, contains items 30-55
B 1 98MW4201 MAIN BEARING ASSY=MWF77 Assembly, contains items 30-55
A 2 98CMCR0950 SHAFT RETNR SPACER METRIC
B 2 98CMCR4216 RESISTOR 42X 225W 5% 10 OHM
all 3 98CMCR0949 COVER SHAFT RETAINER METRIC
B 4 15K253M HEXCAPSCR M24-3.0X75CLS10.9 Z
A 5 15U316M FLTWASH D16 HARD HV200 D16 Z
B 5 15U393 FLTWASH 1" HARD ASTM F436
all 6 15K232M HEXCAPSCR M20X50 10.9 ZINC
A 7 15K127M HEXFLGSCR 3/8-16 X2.5 GR8 ZINC
B 7 15K191HM HEXCAPSCR M12*90 GR10.9 CS
A 8 15G206M HEX NUT M10 ZINC
B 8 15G230M HEXNUT M12 GRADE 10.9 CS
A 9 15K180M M10-1.5X50HX HD CAP SCR DIN931
B 9 15K191CM HEXCAPSCR M12*65 GR10.9 CS
A 10 15U266 FLATWASHER 1"0DX7/16"IDX3/16"
B 10 15U283 12MM WASHER HARD DIN 6916 ZINC
A 11 20C040B SUPERFLEX CLR RTV SIL 10.1OZ
B 12 20C007G THDLOCKSEAL LCT24231 RMUBL50CC
all 13 15B201 HEXCAPSCR M20-2.5 X 50M 18-8
all 14 98CMCR3023 SHAFT RETNR SPACER=3022X CSM
all 15 98CX932503 PIPE FITTING, 90 DEGREE, .25X1/8 BSP
all 16 98CX961460A SLEEVE DELRIN 6MM
all 17 98CX961460 TUBE INSERT 4MM
all 18 98CX932801 PIPE FITTING, 6.5X1/4 BSP
all 19 15U281A WASHER=CLIPPED 1/2 ID .06THK
all 20 01 10025Z NPLT:BEARING&SEAL LUB-42"& 36"
all 21 98CX931701 HEXBUSH, 1/4X1/8 BRASS BSP
all 22 98CX961708 GREASE FITTING, 1/8BSP ZINC
all 23 98CX910823 FLEXIBLE TUBING, 4X6MM OD
A 24 60C170 ORING 8"IDX3/16CS BUNA70 #369
B 24 60C176 ORING 10 IDX1/4"CS BUNA-N#449
A 27 54A337 CUP 6535 SKF 1/BOX
A 28 54A336 CONE 6580 S-ROW S-BORE SKF1/BX
B 29 54AT101190 TIMK HH221449/HH221410=4"BORE
A 30 98MW3611 MACH=MAIN SHAFT MWF45
B 30 98MW4211 MACH=MAIN SHAFT MWF77
A 31 98CMCR3612 MACH=FRONT SEAL HOLDER 36X
B 31 98CMCR4214 MACH=FRONT SEAL HOLDER 42X
A 32 98CMCR3613 SEAL SLEEVE=BRG ASSY 36X
B 32 98CMCR4215 SEAL SLEEVE=BRG ASSY 42X
A 33 02 21542 FRONT GREASE SHIELD 3630F
Bearing Assembly & Installation MWF45, MWF63, MWF77
5 of 6
BPWMCB01 / 2017366A
BPWMCB01 0000161056 A.3 12/7/17 3:32 PM Released
