4
PELLERIN MILNOR CORPORATION
BMP130081/2018195A
MWF45J8, MWF45Z8, MWF63J7, MWF63Z7, MWF77J7, MWF77Z7
MWF63C7, MWF63Y7, MWF77C7, MWF77Y7
Item
Part Number
Description
Comments
Used In
Find the correct assembly first, then find the needed components. The item letters (A, B, C, etc.) assigned to assemblies are referred to in the
"Used In" column to identify which components belong to an assembly. The item numbers (1, 2, 3, etc.) assigned to components relate the
parts list to the illustration.
Parts List—5 Compartment Supply
--------------------------------------------------------------------------------------------COMPONENTS------------------------------------------------------------------------
all 1 96TCC2AA71 3/8" N/C 2WAY 240V50/60C VALVE
all 2 96TDC2AA71 1/2"N/C2WY240V50/60C VLV
all 3 96M001 1/2X3/8" RELIEF VALVE SET31#
all 4 02 03870D FLEXTUBE=2"ID X 14"LG W/CUFFS
Page (2 / 2)
5 Compartment Supply
87
